JB Pipepuller 1700 - Corded Remote Wiring Diagram

Troubleshooting l JB Pipepuller
28
Red
Red
Red
Red
Volt Meter
Solenoid Set
Contact
Solenoid Release
Contact
10
20
30
40
Blk
INTERSTATE
SRM-4D 12 Volt
Marine/RV
Deep Cycle Battery
Cole Hersee Master
Disconnect
Chassis Ground
(Minimum 11 Volts)
V
Hydraulic Motor
M
Cordless Remote
Push Button
10 Amp
Standard
Blade Style
Fuse
50
60
70
80
90
Blk
Blk
Grn
Grn
Purple
Set Solenoid
S
Grn/Yel
Set Coil
Release Solenoid
Yel
Purple
S
Wht
Yel
Release Coil
30
40
Blk
Blk
Set Push
Button
Release
Push
Button
4
2
1
Corded Remote Push Button
