Powered Subwoofer BASS20
TABLE OF CONTENTS
Specifications .................................................................1
Features..........................................................................1
Powered Sub Test Setup...............................................2
Test Procedure...............................................................3
Important Service Note ..................................................4
Block Diagram ................................................................5
Amplifier Exploded View ................................................6
Cabinet Assembly Exploded View.................................7
Parts Lists.......................................................................8
Packaging View............................................................10
Printed Circuit Boards .................................................11
Integrated Circuit Diagram ...........................................13
Schematic Diagrams ...................................................14
SPECIFICATIONS
Amplifier Power (RMS) .......150Watts
Low Frequency Woofer (2) ......81/2"
Design.............Bass reflex enclosure, Grey or White
Inputs .............Line Level and Speaker Level
Outputs ............Full Range Speaker
Crossover Frequency ........120Hz
Frequency Response ........40Hz - 120Hz (+/-3dB)
External Dimensions (Inches)
Height .............17-3/4"
Width .............10"
Depth .............24"
External Dimensions (mms)
Height .............451
Width .............254
Depth .............610
Weight.............42lbs (19.1kg)
FEATURES
n
The Bass20 powered subwoofer is part of the SCS120 or
MUSIC 20 System.
n
150 watt output.
n
Variable level control.
n
Line level or Speaker level inputs, outputs for full range
satellite speakers.
n
User friendly auto on circuit. Signal sensing
automatically turns the subwoofer on so you don’t have
to; the subwoofer is meant to be left on without
continual use of the power switch.
