JBL CS Series Service Manual

Part Number Description Qty Reference Designator
220880302 Resistor RD 1/8W 3K 4 R39 R38 R18 R9
220880363 Resistor RD 1/8W 36K 1 R51
220880392 Resistor RD 1/8W 3.9K 1 R13
220880470 Resistor RD 1/8W 47Ω 8 R145,245,345,445 R158,258,358,458
220880472 Resistor RD 1/8W 4.7K 4 R146,246,346,446
220880473 Resistor RD 1/8W 47K 10 R34 R101,201,301,401 R102,202,302,402 R1
220880474 Resistor RD 1/8W 470K 1 R44
220880562 Resistor RD 1/8W 5.6K 4 R155,255,355,455
220880563 Resistor RD 1/8W 56K 9 R109,209,309,409 R110,210,310,410 R52
220880682 Resistor RD 1/8W 6.8K 2 R46 R16
220880751 Resistor RD 1/8W 750Ω 4 R111,211,311,411
220880821 Resistor RD 1/8W 820Ω 4 R153,253,353,453
220880913 Resistor RD 1/8W 91K 4 R100,200,300,400
230881001 Resistor MF 1/8W 1K 1% 4 R103,203,303,403
230881002 Resistor MF 1/8W 10K 1% 1 R48
230881003 Resistor MF 1/8W 100K 1% 4 R105,205,305,405
230881052 Resistor MF 1/8W 10.5K 1% 1 R47
230882202 Resistor MF 1/8W 22K 1% 1 R8
230884751 Resistor MF 1/8W 4.75K 1% 6 R213 R413 R112,212,312,412
230884991 Resistor MF 1/8W 4.99K 1% 2 R113 R313
207T15B24 VR WH9011A-2-18T B20K 2 VR101 VR201
232XL502J Resistor SQM 5Ws 0.2Ω 8 R149,249,349,449 R150,250,350,450
261T05103 Thermistor NTC THERMISTORD103J 10K 2 RTH1 RTH2
Capacitors
31J510110 Capacitor C/C NPO 100PF/100V J 4 C101,201,301,401
31K510210 Capacitor C/C 1000PF/100V K 4 C103,203,303,403
31Z510305 Capacitor C/C Y5V 10000P/50V Z 1 C35
31Z510410 Capacitor C/C Y5V 0.1UF/100V Z 8 C32 C31 C6 C7 C8 C9 C10 C11
31J522110 Capacitor C/C NPO 220PF/100V 2 C13 C12
31J547010 Capacitor C/C NPO 47PF/100V J 16
C136,236,336,436 C142,242,342,442 C137,237,337,437
C105,205,305,405
31K547310 Capacitor C/C 0.047UF/100V K 2 C37 C38
31J568125 Capacitor C/C Y5E 680P/250V K 1 C22
32J510410 Capacitor M/C 0.1UF/100V J 8 C143,243,343,443 C138,238,338,438
32J568210 Capacitor M/C 0.0068uf/100V J 1 C20
340Z10625 Capacitor 10UF/25V 5*11 6 C112 C212 C129,229,329,429
340Z10716 Capacitor 100U/16V 5*11 10 C19 C28 C27 C141,241,341,441 C4 C29 C30
340Z10750 Capacitor 100UF/50V 8*13 8 C135,235,335,435 C140,240,340,440
340Z22550 Capacitor 2.2UF/50V 5*11 2 C34 C33
340Z22616 Capacitor 22UF/16V 1 C21
340Z22625 Capacitor 22UF/25V 5*11 10 C2 C3 C100,200,300, C402 C104,204,304,404
340Z47625 Capacitor 47UF/25V 5*11 3 C5 C36 C14
370Z10550 Capacitor 1UF/50V 5*11 4 C139,239,339,439
370Z10716 Capacitor 100UF/16V 8*12 1 C18
370Z22616 Capacitor 22UF/16V NP 1 C1
390Z22625 Capacitor 22UF/25V 4*7 4 C102,202,302,302 C400
341T22835 Capacitor 2200UF/35V 16*26 105C 4 C23 C24 C25 C26
341T10835 Capacitor 1000UF/35V 13*26 105C 3 C15 C16 C17
Miscellaneous
571T20070 Wire 1015# 20AWG 70MM 1 GND
572TB6012 Wire 12Pin 60MM(CN*2) 1 J4
172T41026 Coil T23*90-26 1.2*5 2.6uH 1 L1
182T37510 Transformer φ37 5:10 F=1.0*5 S=1.2*3 1 T1
435T00025 Fuse 25A ATC 2 F1
447T00001 Fuse Holder PCB Fuse Holder 1 F1
526URDW14 RCA Jack RCA Jack 1 RCA1
535T25002 Connector 2Pin P=2.5MM 90 1 J3
544T300003 Terminal GA30-03-3P 1 J1
544T34324 Terminal EM-2304 4P*213.3 1 J2
11
CS Series 50.4
