JBL CS680 (230V) User Manual

7
English
SUBWOOFER CONTROLS
Rear Panel
AC 220V-230V
50Hz-60Hz
220 Watts
PHASE
CS80SUB/230
¡
™
£
¢
∞
§

Subwoofer-Level Control

Phase Switch

LFE Input

Line-Level Inputs

Power Indicator LED

Power Switch
Subwoofer Connections
If you have a Dolby
®
Digital or DTS
®
receiver/processor with a
low-frequency-effects (LFE) or subwoofer output:
SUBWOOFER OR
LFE OUTPUT
RECEIVER/PROCESSOR
4.5m (15')
Subwoofer
cable included
NOTE: If your receiver/processor has only one sub out, you may use
either the L or R input.
If your receiver/processor does not contain a Dolby Digital or DTS
processor but has a subwoofer output:
4.5m (15')
Subwoofer cable
included
RECEIVER/PROCESSOR
Important!
Whenever changing cables, pulling plugs, etc., ALWAYS TURN OFF
ALL EQUIPMENT, including the subwoofer.
