Figure 2.2.1 Dimensions
Figure 2.2.2 Mounting Kit
long angle bracket
flat bracket
front angle bracket
rear angle brackets
rear flat brackets
218.44 mm [8.6 in]
303.4 mm [11.9 in]
43.3 mm
[1.7 in]
CSA 1120 z
