DSC260 Preliminary Owners Manual Revision 0.9
28
Limiter Settings for Power Levels into 4 ohms per channel
Power Amp 75 w 150 w 200 w 300 w 500 w 600 w 800 w 1200 w 2400 w
MPA 275 -4 dBu -1 dBu 0 dBu
MPA 400 -6 dBu -3 dBu -2 dBu 0 dBu
MPA 600 -8 dBu -5 dBu -4 dBu -2 dBu 0 dBu 1 dBu
MPA 750 -9 dBu -6 dBu -5 dBu -3 dBu -1 dBu 0 dBu
MPA 1100
-11 dBu
-8 dBu
-7 dBu
-5 dBu
-3 dBu
-2 dBu
-1 dBu
1 dBu
MPX 300 -4 dBu -1 dBu 0 dBu 2 dBu
MPX 600 -8 dBu -5 dBu -4 dBu -2 dBu 0 dBu 1 dBu
MPX 1200 -11 dBu -8 dBu -7 dBu -5 dBu -3 dBu -2 dBu -1 dBu 1 dBu
Limiter Settings for Power Levels into 8 ohms per channel
Power Amp 75 w 150 w 200 w 300 w 500 w 600 w 800 w 1200 w 2400 w
MPA 275 -4 dBu 2 dBu
MPA 400 -3 dBu 0 dBu 1 dBu
MPA 600 -5 dBu -2 dBu -1 dBu 1 dBu
MPA 750 -6 dBu -3 dBu -2 dBu 0 dBu 2 dBu
MPA 1100 -8 dBu -5 dBu -4 dBu -2 dBu 0 dBu 1 dBu 2 dBu
MPX 300 -1 dBu 2 dBu
MPX 600 -5 dBu -2 dBu -1 dBu 1 dBu 3 dBu
MPX 1200 -8 dBu -5 dBu -4 dBu -2 dBu 0 dBu 1 dBu 2 dBu
Bridge Mode Limiter Settings for Power Levels into 8 ohms
Power Amp 75 w 150 w 200 w 300 w 500 w 600 w 800 w 1200 w 2400 w
MPA 275 -7 dBu -4 dBu -3 dBu -1 dBu 1 dBu
MPA 400 -9 dBu -6 dBu -5 dBu -3 dBu -1 dBu 0 dBu 1 dBu
MPA 600 -11 dBu -8 dBu -7 dBu -5 dBu -3 dBu -2 dBu -1 dBu 1 dBu
MPA 750 -12 dBu -9 dBu -8 dBu -6 dBu -4 dBu -3 dBu -2 dBu 0 dBu
MPA 1100 -14 dBu -11 dBu -10 dBu -8 dBu -6 dBu -5 dBu -4 dBu -2 dBu 1 dBu
MPX 300 -7 dBu -4 dBu -3 dBu -1 dBu 1 dBu 2 dBu
MPX 600 -11 dBu -8 dBu -7 dBu -5 dBu -3 dBu -2 dBu -1 dBu 1 dBu
MPX 1200 -14 dBu -11 dBu -10 dBu -8 dBu -6 dBu -5 dBu -4 dBu -2 dBu 1 dBu
