DVD600 Electrical Parts List
Ref. Designator Part Number Description Qty
MAIN PCB
'090 J60600008000 SHIELD MPEG FRONT 1.000
CC203 J4111212000X CABLE 21P 200 1.000
CC207 J4112122001X CABLE 12P 200 1.25 1.000
CN200 J4350009914X CNT 17P SHELD 650 2.0#24 1.000
CP206 J4420031240X CNT PLUG12P 2.0MM 1.000
CP212 J4420030240X CON WAFER 2P 2.0 1.000
CP213 J4420030440X CNT PLUG 4P 2.0MM 1.000
CP214 J4420031140X CNT ST 11P 2.0 1.000
FC101 J2632400016X FERRITE CORE 12 BOAM 1.000
FC103 J2632400026X FERRITE CORE 14 BOAM 1.000
FC104 J2632400026X FERRITE CORE 14 BOAM 1.000
FC105 J2632100016X EMI CORE RING34 34*21*12 1.000
LM201 J2612222023X COIL RA 22UH K 1.000
L206 J2612222923X 2.2UH KS0606-2R2K 1.000
X201 J3914010036X CRYSTAL 27M 16.5PF 1.000
CM207 J3470010106X CE 100UF 16V 1.000
CM208 J3515100270X CC CHIP 10PF 50V D 1.000
CM209 J3515100270X CC CHIP 10PF 50V D 1.000
CM210 J3515100270X CC CHIP 10PF 50V D 1.000
CM211 J3515100270X CC CHIP 10PF 50V D 1.000
CM212 J3515100270X CC CHIP 10PF 50V D 1.000
CM213 J3515100270X CC CHIP 10PF 50V D 1.000
CM214 J3515100270X CC CHIP 10PF 50V D 1.000
CM215 J3515100270X CC CHIP 10PF 50V D 1.000
CN203 J4422402123X FPC ST 1.0 21P 1.000
CN208 J4422501327X FPC ANG 1.0 13P 1.000
CP202 J4422401523X FPC ST 1.0 15P 1.000
CP207 J4422411220X FPC ST 1.25 12P 1.000
CP802 J4425031040X CNT SMD 10P 2.0 1.000
C206 J3515100270X CC CHIP 10PF 50V D 1.000
C211 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C213 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C214 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C215 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C216 J3470010106X CE 100UF 16V 1.000
C217 J3525103170X CC/CHIP .01U 50V K 1.000
C218 J3515331170X CC/CHIP 330PF 50V J 1.000
C219 J3525332170X CC/CHIP 3300PF 50V 1.000
C220 J3525103170X CC/CHIP .01U 50V K 1.000
C221 J3470010106X CE 100UF 16V 1.000
C222 J3470010106X CE 100UF 16V 1.000
C223 J3525103170X CC/CHIP .01U 50V K 1.000
C226 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C227 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C228 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C229 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C230 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C239 J3515220270X CC/CHIP 22P 50V 1.000
C240 J3515220270X CC/CHIP 22P 50V 1.000
C241 J3525104540X CC/CHIP 0.1U 25V Z 1.000
C242 J3525104540X CC/CHIP 0.1U 25V Z 1.000
