JBL DVD600 - Packing;Accessories

Ref. Designator Part Number Description Qty
R874 J3024331120X R-CHIP 330 2012J 1.000
R875 J3024470120X RES CHIP 47 1/10W 1.000
R876 J3024471120X RES CHIP 470 1/10W 1.000
R878 J3024331120X R-CHIP 330 2012J 1.000
R879 J3024331120X R-CHIP 330 2012J 1.000
R880 J3024102120X RES CHIP 1K 1/10W 1.000
R881 J3024102120X RES CHIP 1K 1/10W 1.000
SENSOR PCB (MECH CONTROL PCB)
R001 5088295016 RCF 100R0 OHM +5% 250M10W 1.000
R002 5088295016 RCF 100R0 OHM +5% 250M10W 1.000
C001 80434590AF CC 22P0F +5% -5% 50.0V NP0 1.000
C002 20246950AF CC 100N0F +10% -10% 25.0V Y5R 1.000
C003 80434590AF CC 22P0F +5% -5% 50.0V NP0 1.000
C004 20246950AF CC 100N0F +10% -10% 25.0V Y5R 1.000
C005 20268030AM CE 1MI0F +20% 25.0V 85C 1.000
D001 2041428001 D-ZENER 1N5232B 5.6V 500MI0W 1.000
D002 2041428001 D-ZENER 1N5232B 5.6V 500MI0W 1.000
IC001 20656300NR IC-MOTORCIR LB1641 MOTOR CONT WITH LOGI 1.000
IC002 20656300NR IC-MOTORCIR LB1641 MOTOR CONT WITH LOGI 1.000
L001 20265120NR LF 39U0H +10% 130MI0 OHM 1.5A 1.000
PI001 20586840NR D-PHOTO RPI-574 1.000
PI002 20586840NR D-PHOTO RPI-574 1.000
PI003 20586840NR D-PHOTO RPI-574 1.000
PI004 20556130NR D-PHOTO GP2S28 20MI0A 1.000
P003 20504010XX CONN 2.0MM 6 MA ST NAT JST,B6B-PH-K 0 0 1.000
P004 20713210XX WCL 150-05-05 UL2468 RIBBON 26 150MM NON 1.000
P027 20713500NR WCASSY 06187F 06 180MM UL20080 RIBBON SO 1.000
P406 J4350009909X CNT 12P 280 #26 2 1.000
P406B 20649240XX WCL 060-05-05 UL2468 RIBBON 26 60MM NONE 1.000
R003 2054943001 RCFF 2R2 OHM +5% 250MI0W 1.000
R004 2054943001 RCFF 2R2 OHM +5% 250MI0W 1.000
POWER SUPPLY
DVD600 Power Supply module, JBL part#
55174740 is supplied only as
a complete unit.
DVD600 LASER PICK-UP ASSEMBLY, COMPLETE SEE SERVICE BULLETIN JBL2003-01
PACKING/ACCESSORIES
J96000038210 BOX CARTON DVD600 1.000
J97200037000 CUSHION FRONT 1.000
J97200013010 CUSHION REAR 1.000
J94330001000 CORD RCA 3P1500 JW-8103M 1.000
J94310004000 MONO PLUG 1P JW-810 1.000
J94310007000 CORD RCA 1P 01000 1.000
J94310009000 CORD RCA 1P Y 1000 1.000
AI5115 CINEMA PROPACK 600 OWNER'S MANUAL
DVD600
47
