15
A. CH 1 XLR Male Loop Thru
This XLR output connector provides a method of sending audio
out to an external source. The XLR male connector will take a
direct feed of the input on its respective channel, and send it out
at the same level.
B. CH1 XLR-1/4” Combo Input
XLR – 1⁄4” combination connector (1 for each input) are used
for the analog audio inputs.
C. LCD Display
The LCD is used to display basic diagnostic information and
allow access to more advanced features through a menu
system. See the LCD GUI specification for more details on
the LCD menu system, features, and navigation. The LCD will
refresh at approximately 4Hz and is not suitable for meters or
any other fast motion items.
D. Power Button
Press the Power Button for .5 second to engage power.
Press the Power Button for .5 second to disengage power.
E. Main Volume / Menu Navigation
Controls LCD Display
• Rotary encoder: In Menu - Clockwise down menu/Anti-
clockwise up menu
• Press to select menu item
• + On Home screen, Main Volume increase by rotating the
knob clockwise.
• + On Home screen, Main Volume decrease by rotating the
knob counterclockwise.
F. Back Button
Press to return to previous menu item
G. CH2 XLR-1/4” Combo Input
XLR – 1⁄4” combination connector (1 for each input) are used
for the analog audio inputs.
H. CH 2 XLR Male Loop Thru
This XLR output connector provides a method of sending audio
out to an external source. The XLR male connector will take a
direct feed of the input on its respective channel, and send it out
at the same level.
I. AC Power Connector
Inlet adapter for A/C power cable
MIXER PANEL FUNCTIONS
