Part Number Description Qty Reference Designator
MAIN PCB
130-3f104z503-e Disc Capacitor 0.1U 50V +80/-20% (RoHS) 2 C163,C164,
130-ch101j503-e Disc Capacitor100P 50V ±5% (RoHS) 2 C159,C160,
135-3107m16-e electrolytic cap 100uF 16V ±20% (RoHS) 2 C166,C167,
135-3226m50-e electrolytic cap 22U 50V ±20% (RoHS) 2 C161,C162,
135-3227m10-e elec trolytic cap 220U 10V ±20% (RoHS) 2 C156,C157,
139-3227m16-e low leakage ec 220uF 16V±20% (RoHS) 1 C155,
140-RX473KB03-E multy layer cap 47NF 200V X7R ±10% (RoHS) 2 C172,C173,
140-rx103ka03-e multy layer cap 10nF 100V X7R 10%立式 (RoHS) 1 C174,
Semiconductors
190-16l431clp1-e
IC TL431CLP (RoHS) PROGRAMMABLE VOLTAGE REFERENCE
1 D115
192-027c1815gr-e transistor 2SC1815GR TOSHIBA(RoHS) NPN 4 Q110,Q112,Q114,Q117,
192-028a1015gr-e transistor 2SA1015GR TOSHIBA(RoHS) PNP 3 Q111,Q113,Q115,
192-1572n5551-e transistor FSC 2N5551 (RoHS) NPN 1 Q109,
192-1582n5401-e Transistor FSC 2N5401 AI-PNP 350V500mA TO-92 (RoHS) 1 Q108,
197-631n4148-e diode 500mW 75V 1N4148 Panjit (RoHS) 7 D117,D118,D119,D120,D121,D126,D125,
199-65000563g-e Zener diode GDZJ5.6B 500mW 5.6V 2% (RoHS) 1 D116,
199-65001503g-e Zener diode GDZJ15C500mW 15V 2%ROHM 52mm 1N5245B 1 D122,
199-65002003g-e Zener diode GDZJ20D 500mW 20V 2% (RoHS) 1 D129,
190-16lm324n-e I.C. LM324N (RoHS) QUAD OP-AMP 1 U107,
192-991d669a-e transistor HI-SINCERITY HSD669A (RoHS) NPN 1 Q116,
192-992b649t-e transistor HSB649T (RoHS) PNP 1 Q118,
197-00db103g-e DIODE 1A 200V DF02M 1 D124,
197-00kbu1003-e DIODE 10A 200V KBU1003 1 D123,
197-101n4002-e DIODE 1N4002TB (RoHS) 1 D114,
Miscellaneous
109-1tsc103j0-e THERMISTOR TSC05103J (RoHS) 1 R237,
171-udhss124d-e RELAY 5A 24V UDH-SS124D 1 K101,
175-1c02v01-e WIRE CONNECTOR 2PIN PITCH=2.5mm (RoHS) 1 P108,
175-1c06v01-e WIRE CONNECTOR 6 PIN PITCH=2.5mm 1 P107,
175-1d02v01-e WIRE CONNECTOR 2PIN PITCH=3.96mm 1 P112,
175-1d05v01-e WIRE CONNECTOR 5PIN 3.96mm (RoHS) 1 P113,
362-FE-00041-0LAE PCB SUPPORT 11.75*8.5*12.5H 1
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
Resistors
118-12061001f-e SMD RESISTOR 1K 1206 1% (RoHS) 1 R2,
118-12061002f-e SMD RESISTOR 10K 1206 1% (RoHS) 1 R25,
118-12061002j-e SMD RESISTOR 10.0K 1206 5% (RoHS) 5 R29,R30,R30B,R7,R9,
118-120610r0j-e SMD RESISTOR 10.0Ω 1206 5% (RoHS) 4 R20,R20B,R22,R23,
118-12062002f-e SMD RESISTOR 20K 1206 1% (RoHS) 1 R26,
118-12062201j-e SMD RESISTOR 2.20K 1206 5% (RoHS) 18
R13,R16,R31,R33,R34,R35,R36,R37,R38,
R39,R40,R41,R42,R43,R44,R45,R46,R32,
118-12062204j-e SMD RESISTOR 2.20M 1206 5% (RoHS) 1 R4,
118-12062211f-e SMD RESISTOR 2.21K 1206 1% (RoHS) 1 R6,
118-12062550f-e SMD RESISTOR 1206 255Ω 1% (RoHS) 1 R24,
118-12062701j-e SMD RESISTOR 2.70K 1206 5% (RoHS) 1 R10,
118-12063301j-e SMD RESISTOR 3.30K 1206 5% (RoHS) 4 R14,R15,R27,R28,
118-12063321f-e SMD RESISTOR 3.32K 1206 1% (RoHS) 1 R1,
118-12063922f-e SMD RESISTOR 1206 39.2K±1% (RoHS) 1 R3,
118-12064700j-e SMD RESISTOR 470Ω 1206 5% (RoHS) 3 R8,R11,R21,
118-12064701j-e SMD RESISTOR 4.70K 1206 5% (RoHS) 1 R12,
118-12064751f-e SMD RESISTOR 4.75K 1206 1% (RoHS) 1 R5,
112-10180j00-e FUSE RESISTOR FMF 1W 18Ω 5%(RoHS) 1
20
ES250P
