JBL ES250P - Page 22

Part Number Description Qty Reference Designator
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
Capacitors
141-d7104ka0-e SMD CAPACITOR 0.1uF 100V 10% 1210 X7R (RoHS) 2 C18,C19,
141-d7104kb5-e SMD CAPACITOR 0.1uF 250V 10% 1210 X7R (RoHS) 2 C12,C14,
141-c0101k50-e SMD CAPACITOR 100pF 50V 10%1206 NP0 (RoHS) 1 C4,
141-c0220k50-e SMD CAPACITOR 22pF 50V 10% 1206 SMT NPO (RoHS) 1 C5,
141-c0561k50-e SMD CAPACITOR 560pF 50V 10% 1206 NPO (RoHS) 1 C6,
141-c5104m50-e SMD CAPACITOR 1206 Y5V 0.1uF 50V ±20% (RoHS) 8 C2,C3,C7,C8,C9,C10,C11,C15,
141-c7103k50-e SMD CAPACITOR 10nF 50V 1% 1206 X7R (RoHS) 1 C13,
128-e106ma01-e CROSSVER CAP. 10uF 100V 20% (RoHS) 2 C16,C17,
130-sl681kb03-e Disc capacitor SL 680PF 200V (RoHS) 1 C21
132-104kb50-e MYLAR CAPACITOR 0.1U ±10% 250V LS-10.mm MD (RoHS) 1 C20,
132-105kb50-e MYLAR CAPACITOR 1uF 250V ±10% (RoHS) 1 C40,
Semiconductors
190-16tl072dts-e SMD I.C. TL072CDT SGS THOMSON(RoHS) DUAL OP-AMP 1 IC1,
192-09124126qs-e SMD TRANSISTOR 2SC2412K-T146Q/R ROHM (RoHS) 2 Q1,Q4,
192-09139066rs-e SMD TRANSISTOR 2SC3906K-T146R ROHM (RoHS) 2 Q2,Q8,
192-091sc4672-e TRANSISTOR 2SC4672(MPT3) ROHM (RoHS) 1 Q5B,
192-09210376qs-e SMD TRANSISTOR 2SA1037K-T146Q/R ROHM (RoHS) 2 Q7,Q9,
192-09215146rs-e SMDTRANSISTOR 2SA1514K-T146R ROHM (RoHS) 1 Q3,
192-1582n5401-e TRANSISTOR FSC 2N5401 AI-PNP 350V 500mA TO-92 (RoH
S
1 Q6B,
197-03rls4148s-e SMD DIODE RLS4148-TE11 ROHM (RoHS) 8 D1,D2,D3,D4,D5,D5B,D6,D20,
199-15000563s-e SMD ZENER DIODE 5.6V 5% PHILIPS BZX84-C5V6 (RoHS) 2 Z1,Z2,
199-1500120s-e SMD ZENER DIODE 12V 5% PHILIPSBZX84-C12 (RoHS) 4 Z3,Z4,Z5,Z6,
192-232irf9640-e TRANSISTOR FET IRF9640 IR P-CH TO220 (RoHS) 2 Q10,Q10B,
192-233f640n-e TRANSISTOR IRF640N INTERNATIONAL (RoHS) 1 Q11,
Miscellaneous
122-13151k0190-e CHOKE SA-500-280 (PT1601B*151MAA) (RoHS) 1 L1,
122-14300k4-e Ferrite core LD1215*300KU ±10% (RoHS) 1 L2,
175-9F02H02-E WIRE CONNECTOR&BASE 2PIN PITCH=2.54mm (RoHS) 1 HDR3,
175-9F03H020-E WIRE CONNECTOR&BASE 3PIN PITCH=2.54mm (RoHS) 2 HDR1,HDR2,
MISC./MECHANICAL & AC INPUT PCB
128-C117JA01-E electrolytic CAP 110uf 100V 1 On Woofer terminals
150-r1107011-e RING POWER TRANSFORMER TT0930505260 (RoHS) 1
152-u60201a02-e LINE CORD 6FT UL 2PIN SOCKET PRONIC (RoHS) 1
153-vpst101s2-e AC OUTLET&SOCKET VDE 2PINS INLET 1
154-k31505t0-e FUSE 3.15A 250V 30mm UL/CSA/PSE (RoHS) 1
155-630r345b-e FUSE HOLDER UL/CSA ψ6*30mm R3-45B (RoHS) 1
162-10100023-e WIRE UL/CSA 1617 #22 100mmBLK (RoHS) 1
162-10151001-e WIRE UL1617 150mm 22AWG BROWN6:6 (RoHS) 1
162-5016d001-e WIRE 24# 160mm BLK (RoHS) 1
162-5020d006-e WIRE UL2468 200mm 2.5mmpitchRED/WHT (RoHS) 1
162-a055d002-e WIRE ASS'Y 550mm UL2468 26AWG紅白+Housing+Φ5LED 1
166-5070a4bd-e SPEAKER WIRE 700mm #18 #205*0.5t BLK/#250*0.8t紅(RoH
S
1
180-prf1003b-e SWITCH ROCK RF-1003-BB210(RoHS) POWER 1
193-0s4211-e INSULATOR (INSULATION SPACER)42*11 (RoHS) 1
193-201612tr-e INSULATOR T0-220 16mm*12mm(RoHS) 3
236-AL-05001-0LAE RETAINER (RoHS) 1
302-AL-05086-0BBE REAR BOARD 300*200*2.5T ES250/120V 用(RoHS) 1
306-ABS-05081-0BA
E
REAR Housing 198*298*102mm後WITH 8 PIECE EVA (RoHS) 1
311-ABS-00028-0BA
E
KNOB 46077-W P.V.C.(RoHS) LEVEL, CROSSOVER 2
323-AL-05000-0LAE HEAT SINK (RoHS) 1
325-FE-00400-0LAE PCB FLOOR STAND 58*9*13.5T (RoHS) 1
333-EVA-00188-0BA
E
EVA GASKET 170x5x1t with glue (RoHS) 1
333-EVA-00220-0BA
E
EVA GASKET LONG 225*15*1t UL(RoHS) 1
333-EVA-00866-0BA
E
EVA 48*18*1.5T (RoHS) 1
333-SPG-00860-0BA
E
FIREPROOFING GASKET 450*50*5T (RoHS) 1
21
ES250P
