Dolby Pro-Logic
Ò
Surround Processor/Amplifier ESC200
Ref. # Part # Description Qty
Q14 1-07-001 NPN NEC 9011G 1
U18 1-09-056A IC, UPD75106CW-240 NEC -2552B 1
MICROPROCESSOR
XTAL2 1-03-107 CER-RESONATOR, 1
CSA4.19MHZ MURATA
MECHANICAL PARTS LIST
1 5-01-257 120V TOP COVER 1
5-01-262 230V TOP COVER 1
2 7-71-077 FRONT PANEL 1
3 5-01-256 120V BOTTOM COVER 1
5-01-258 230V BOTTOM COVER 1
4 7-01-078 LENS ACRYLIC 1
5 1-42-013 KEYPAD FOR PANEL 1
6 3-61-009A LOGO BADGE 1
7 1-40-063 RUBBER FOOT K137 4
8 1-01-117 T1 120V TOROIDAL TRANS. 1
1-01-084 T1 230V TOROIDAL TRANS. 1
9 3-71-088 HEAT SINK 1
10 3-71-062 HEAT SINK FOR 7805 1
11 3-71-061 HEAT SINK FOR 7809 1
12 1-09-092 LM1876TF 3
13 MAIN PCB 1
14 1-43-003 2 RCA JACK HSP-212V-09 GP 3
15 1-08-0006 REGULATOR 7809 1
16 1-08-158 REGULATOR 7805 1
17 1-44-119 SPEAKER TERMINAL 3
HSP-104HL-05
18 1-51-367 120V AC CORD 1
1-51-356 230V AC CORD 1
19 1-29-116 120V FUSE 3A GMA TYPE 1
1-29-098 230V FUSE 1.6A GMA TYPE 1
20 1-29-011 120V FUSE HOLDER 1
1-29-012 230V FUSE HOLDER 1
21 1-44-469 WIRE BUSHING 1
22 1-25-215 LD1 LED DISPLAY SET 1
23 1-05-032 2601-5P DISPLAY PCB 1
24 1-33-378 SCREW 3x8 TTS BZ 4
FOR THE RUBBER FEET
25 1-33-341 SCREW 3x6 TTS-BH BZ 13
FOR PCB & COVER
26 1-33-380 SCREW 3x8 BT BZ 14
FOR RCA JACK & HEATSINK
27 1-34-280 SCREW 2.6x6 KM BZ 6
FOR KEY PCB
28 1-33-300 SCREW 3x6 BT BZ -7809 3
HEATSINK
29 1-34-270 SCREW 2.6x6 BT BZ 13
FOR DISPLAY
Ref. # Part # Description Qty
30 1-33-465 SCREW 3x16 PM BZ 3
FOR IC BRACKET
31 1-37-230 M3 SPRING WASHER ZNC 3
32 1-37-130 M3 FLAT WASHER BZ 7
33 1-37-030 M3 NUT 3
34 1-27-076 POWER SWITCH (ONLY ON 230V) 1
PACKING SECTION
BATTERY 1-01-102 BATTERY GP24G 1.5V SIZE AAA 2
ZINC CHLORIDE BATT.
PACKAGE 2 IN 1
RCA Y-CABLE 1-51-136 WIRE, 2 RCA PHONE PLUG 1
RED(R)/BLK(L) PLUG, +3.5mm
STEREO PLUG/BLK, WITH 2MT
2C100121/2C28012SX2652P
BLK SPIRAL SHIELD WIRE
RCA CABLE 1-51-316 WIRE, 1MT 2
100121/28012SSX2652P
BLK PLUG, SPIRAL SHIELD
WIRE RCA PHONE PLUG
NICKLE-PLATED RED/BLK
BOTH END
WIRES HEC041-00 SPEAKER WIRES 6
OWNER’S MANUAL 0/M ESC200 ESC200 MANUAL 1
REMOTE 9-01-121 REMOTE CONTROL 1
FEET 1-33-378 RUBBER FEET 4
SATELLITES J-SP-SAT ESC200 SATELLITE SPEAKERS 5
SUBWOOFER J-SP-SUB ESC200 SUBWOOFER 1
CARTON XRC145-00 DISPLAY CARTON 1
