Dolby Pro-Logic
Ò
Surround Processor/Amplifier ESC200
8
Ref. # Part # Description Qty
R7, 8 1-17-510 1/8W+-5% PF 100K OHM 2
R11 1-17-439 1/8W+-5% PS 39K OHM T/B 1
R15, 99 1-22-127 3W+-5% WIRE WOUND 27 OHM 2
R16, 102 1-17-412 1/8W+-5% PS 12K OHM T/B 2
R17, 74 1-17-382 1/8W +-5% PS 8.2K OHM T/B 2
R18, 78, 101, 110 1-17-422 1/8W+-5% PS 22K OHM T/B 4
R19, 51, 87, 92 1-17-327 1/8W+-5% PS 2.7K OHM T/B 4
R20 1-17-420 1/8W+-5% PS 20K OHM T/B 1
R21, 24, 69 1-17-375 1/8W +-5% PS 7.5K OHM T/B 3
R22, 26 1-17-447 1/8W+-5% PS 47K OHM T/B 2
R28 1-17-647 1/8W+-5% PS 4.7M OHM T/B 1
R31, 33, 162, 1-17-351 1/8W +-5% PS 5.1K OHM T/B 8
163, 167, 168,
169, 171
R32, 34 1-17-510 1/8W+-5% PS 82K OHM T/B 2
R36 1-17-610 1/8W+-5% PS 1M OHM T/B 1
R37, 55, 65, 1-17-324 1/8w+-5% PS 2.4K OHM T/B 5
88, 103
R38, 56, 66, 75 1-17-430 1/8W+-5% PS 30K OHM T/B 7
76, 89, 100
R40, 63 1-17-418 1/8W+-5% PS 18K OHM T/B 2
R41, 45, 52, 59, 1-17-515 1/8W+-5% PS 150K OHM T/B 12
64, 68, 73, 82,
86, 91, 97, 175
R42, 49, 60, 1-19-010 1/2W+-5% PS 1 OHM T/B 6
70, 83, 93
R43, 50, 61, 71, 1-19-110 1/2W+-5% PS 10 OHM T/B 7
84, 94, 98
R44, 62, 72 1-17-356 1/8W +-5% PS 5.6K OHM T/B 3
R48, 95 1-17-339 1/8W +-5% PS 3.9K OHM T/B 2
R53, 58 1-17-120 RES, 1/8W+-5% PS 20 OHM T/B 2
R85, 112 1-17-215 1/8W+-5% PS 150 OHM T/B 2
R106, 107 1-17-312 1/8W+-5% PS 1.2K OHM T/B 2
R114, 115, 116, 1-17-310 1/8W+-5% PS 1K OHM T/B 4
117
R118, 119 1-17-351 1/8W+-5% PF 5.1K OHM 2
R127 1-17-310 1/8W+-5% PF 1K OHM 1
R128 1-17-433 1/8W+-5% PS 33K OHM T/B 1
R155 1-17-533 1/8W+-5% PS 330K OHM T/B 1
R172, 173 1-17-410 1/8W+-5% PF 10K OHM 2
Transistors
Q15, 16, 17, 18 1-07-004 NPN NEC 9014C 4
Q19 1-07-107 NPN MPSA06 1
Ref. # Part # Description Qty
MISCELLANEOUS SECTION
L1, 2, 3, 4, 5, 6 1-04-011 COIL, SPRING COIL 0.8mm 6
12T D=5.5mm
LD1 1-25-215 LED DISPLAY SET 1
XTAL1 1-03-109 C-RES, CER-RESONATOR, 1
CSA2.0MHZ MURATA
FLAT CABLE PITCH=2mm UL
3 PINS 160MM(10+10) 1
1-58-017 WAFER, 12 PINS PITCH=2.5mm 1
1-58-010 WAFER, 3 PINS PITCH=2.5mm 1
1-58-009 WAFER, 4 PINS PITCH=2.5mm 1
FLAT CABLE PITCH=2.54mm 1
16 PINS 60MM(10+3)
HOUSINGFEMALE/MALE
HOUSING P=2.5mm
1-51-372 SET, 12PINS 100mm 1
FEMALE/MALE
1-51-373 SET, 4PINS 200mm 1
FEMALE/MALE
1-51-374 SET, 3PINS 160mm 1
FEMALE/MALE
9-01-122 PCB, 2601-5P UL94V0 1
SWITCH PCB (230V)
KEY PCB SECTION
C34 1-12110LI E.CAP, 16V +-20% 5x11 10UF 1
C168, 173 1-12220KI 10V +-20% 6x11 220UF 2
C174 1-12247KI 10V +-20% 8x12 470UF 1
C175, 176 1-16031PH C.CAP, 50V+-10% 30PF NPO 2
PD1 1-05-039 PHOTO MODULE TSOP1838 1
R130, 132, 134, 1-17-147 RES, 1/8W+-5% PS 47 OHM T/B 9
136, 138, 140,
142, 144, 150
R147, 148 1-17-247 1/8W +-5% PS 470 OHM T/B 2
R153, 174 1-17-310 1/8W +-5% PS 1K OHM T/B 2
R151 1-17-351 1/8W +-5% PS 5.1K OHM T/B 1
R129, 131, 133, 1-17-410 1/8W +-5% PS 10K OHM T/B 13
135, 137, 139,
141, 143, 156,
157, 158, 159,
160
R161 1-17-447 1/8W +-5% PS 47K OHM T/B 1
R154 1-17-610 1/8W +-5% PS 1M OHM T/B 1
R152 1-17-147 1/8W +-5% PF 47 OHM 1
R145, 146, 149 1-17-247 1/8W +-5% PF 470 OHM 3
Q1, 2, 3, 4, 5, 6, 1-07-003 NPN NEC 9013H 8
7, 8
Q9, 10, 11, 12, 13 1-07-002 PNP NEC 9012H 5
To Next Page
