On shelves.
On the wall. Optional bracket,
WB300 or WB300WHT (white).
Mounting Options
On optional stands, FS300 or
FS300WHT (white).
Subwoofer
Surround Speakers
5
– 6 ft.
Satellites and Surrounds
one.Speaker Placement
Satellites
0-2 ft.
Mounting Remote Sensor to Center Speaker.
Place remote sensor at bottom
of center speaker.
Insert support leg through
remote sensor and into
speaker.
Center speaker.
The remote sensor may be placed anywhere using the supplied double-sided tape.
