PROBLEM CAUSES AND SOLUTIONS
Sound only comes from some of the speakers
connected to the amplifier
• Check that the vehicle audio system's source unit's balance and fader controls are set to their
center (midpoint) positions.
• (GX-A604): Check that the setting of the amplifier's Mode Switch matches the input and
speaker connections made to the amplifier
Sound is too quiet, even with the vehicle audio
system's source unit volume all the way up
• Check that the amplifier's Level controls are not turned too low. See Set The Input Level, on
page 12, for information about setting the Level controls.
Sound in the front/rear speakers is distorted • Make sure the amplifier's Crossover Filter switch for the distorted channels is set to HP.
• Set the Crossover control for the distorted channels to a higher setting.
• Check that the distortion is not originating from the vehicle audio system's source unit.
Sound in the subwoofer is distorted • (GX-A604, GX-A602): Set the Bass Boost switch to "OFF."
• (GX-A3001): While listening to bass-heavy music, turn the Bass Boost control all the way
down, and then gradually increase it until the distortion begins to return. Reduce the Bass
Boost control setting slightly to eliminate the distortion and leave it set there.
• Check that the distortion is not originating from the vehicle audio system's source unit.

JBL GX-A3001 Specifications

General

Amplifier class	-
Frequency range	10 - 320 Hz
Audio output channels	1.0 channels
Peak power per channel	415 W
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (2 Ohm)	300 W
RMS power output per channel (4 Ohm)	200 W
DC-in jack	Yes
Line inputs (RCA)	2
Speakers connectivity type	RCA
Product color	Black

Weight and Dimensions

Depth	52 mm
Width	206 mm
Height	291 mm
