SPECIFICATIONS
GX-A604 GX-A602 GX-A3001
Max power (15.5V, 1kHz, 10%THD,
total ch, 2 ohms)
435W 280W
415W (15.5V, 50Hz, 10% THD,
2 ohms)
Rated power output @ 4 ohms 60W x 4 60W x 2 200W x 1
Bridged power output
(4 ohms, 1% THD)
170W x 2 170W x 1 N/A
THD+N at rated power <1% <1% <1%
Signal-to-noise (2V @ 4 ohms) >75dB >75dB >75dB
Effective damping factor (4 ohms) >50 >50 >50
Frequency response (–3dB) 20Hz – 20kHz ±1dB 20Hz – 20kHz ±1dB 10Hz – 320Hz
Maximum input voltage 20V 20V 20V
Maximum input sensitivity 200mV 200mV 200mV
Fuse size 20A x 2 25A 20A x 2
Dimensions (H x W x D) 2-1/16" x 11-13/16" x 8-1/8"
(52mm x 300mm x 206mm)
2-1/16" x 7-13/16" x 8-1/8"
(52mm x 198mm x 206mm)
2-1/16" x 11-7/16" x 8-1/8"
(52mm x 291mm x 206mm)
Weight 5.3 lb (2.4kg) 3.8 lb (1.7kg) 5.3 lb (2.4kg)

JBL GX-A3001 Specifications

General

Amplifier class	-
Frequency range	10 - 320 Hz
Audio output channels	1.0 channels
Peak power per channel	415 W
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (2 Ohm)	300 W
RMS power output per channel (4 Ohm)	200 W
DC-in jack	Yes
Line inputs (RCA)	2
Speakers connectivity type	RCA
Product color	Black

Weight and Dimensions

Depth	52 mm
Width	206 mm
Height	291 mm
