JBL Harman EON208P User Manual

12
Section 5: System Specications
EON208P
Main
Features
Proven JBL sound quality
Bluetooth
®
streaming audio
Ergonomic design with internal cable storage
System
System Type: Portable 2-way full-range loudspeakers with powered mixer
Maximum SPL Output: 121 dB peak
AC input : 100-120 V, 220-240 V 50/60 Hz
Amplier
Design: Class D
System Power Rating: 300 W (2x 150 W stereo)
Output Connector: 2 x 1/4" TS (unbalanced) amplier outputs
Mixer
Channels: 1-4: XLR/1/4" jack combo connectors;
5-6: one pair of 1/4" balanced TRS jacks (stereo), and one pair of RCA jacks (stereo);
7-8: one pair of 1/4" balanced TRS jacks (stereo), and a 3.5mm stereo jack
Phantom Power: CH1 and CH2 have phantom power control and share the same selection switch
Hi-Z Selection: CH3 has a Hi-Z selection switch used for guitar signal input
Output Connectors: Monitor Out: one pair of RCA jacks (stereo), and one pair of 1/4" balanced TRS
jacks (stereo)
Headphone Out: 3.5mm stereo jack
Subwoofer Out: 1/4" balanced TRS jack
Treble/Bass EQ: Per-channel high- and low-shelf lters; +/- 12dB cut and boost
System Limiter: On-board DSP limiting
Speaker
LF Driver: 1x JBL 8" (203mm) woofer
HF Driver: 1x 1" Neodymuim black aluminum dome tweeter
Coverage Pattern: 100° horizontal x 60° vertical
Crossover Frequency: 2 kHz
Crossover Type: 2-way passive network, 2nd order lters (12dB cutoff per octave)
Enclosure: Polypropylene
Suspension/Mounting: 36 mm pole socket
Handles: One on top
Grille: Powder-coated perforated steel
Shipping Package
Dimensions (H x W x D):
22.6" x 30.5" x 15.7" (575 mm x 775 mm x 400 mm)
Net Weight of System: 17.6 kg (38.8 lbs)

JBL Harman EON208P Specifications

General

Bluetooth	Yes
Type	Portable PA System
LF Driver Size	8 inches
HF Driver Size	1 inch
Channels	8
Effects	Reverb
Enclosure Material	Polypropylene
Power Output	300W
Frequency Response	60 Hz - 20 kHz
Speakers	2
Weight	17.6 kg
Dimensions	260 x 260 x 260 mm
Inputs	2 x XLR/TRS combo, 1 x 3.5mm stereo
EQ	2-band
