JBL HARMONY - Harmony Mechanical Parts List

17
CD Player/Tuner Stereo System HARMONY
HARMONY MECHANICAL PARTS LIST
Ref. # Part Number Description Qty Ref. # Part Number Description Qty
1 AFA0079-001 Grill Assembly (Grey) 1
AFA0079-002 Grill Assembly (White)
2 AFA0081-001 Port Assembly 1
3 AFA0081-001 CD Loader 1
4 APE0199-002 Main PCB Assembly (120V) 1
APE0199-001 Main PCB Assembly (230V)
5 APE0200-002 Control PCB Assembly 1
6 APE0231-001 Power PCB Assembly 1
7 BPT0024-001 Filter 1
8 BNP0043-001 PVC Plate, Display Sheet 1
9 BPA0026-AM1 Bottom Cover 1
10 BPA0027-AM1 Rear Cover 1
11 BPB0016-AMO Back Cabinet (Grey) 1
BPB0016-BBO Back Cabinet (White)
12 BPB0018-AM1 Handle Cover (Grey) 1
BPB0018-BB1 Handle Cover (White)
13 APE0200-031 Snooze/Alarm Control PCB Assy 1
14 GAL0091-001 Heat Sink 1
15 BPC0019-001 Wire Cover 2
16 BPD1020-AM0 CD Door (Grey) 1
BPD1020-BB0 CD Door (White)
17 BPF0023-AM1 Front Cabinet (Grey) 1
BFP0023-BB0 Front Cabinet (White)
18 BPH0030-Z01 Screw Holder (Left) 1
19 BPH0036-001 Screw Holder (Right) 1
20 BPH0035-001 PCB Holder 1
21 BPK1038-AN0 Alarm Knob (Grey) 1
BPK1038-BC0 Alarm Knob (White)
22 BPK1052-001 Function Knob (Left) 1
23 BPK1053-001 Function Knob (Right) 1
24 BPK5039-AM0 Volume Knob (Grey) 1
BPK5039-BB0 Volume Knob (White)
25 BPN0063-001 Display Window (Grey) 1
BPN0063-002 Display Window (White)
26 BPN0064-000 LED Lens (Grey) 1
BPN0064-001 LED Lens (White)
27 BRB0006-001 Grill Retainers (Grey) 6
BRB0006-002 Grill Retainers (White)
28 RBR0007-001 Rubber Foot (Grey) 8
BRB0007-002 Rubber Foot (White)
29 BRB0012-001 Plugger 1
30 BRB0013-001 Socket Rubber 1
31 CLJ0010-001 Logo Plate 1
32 DSU0020-001 Spring 2
33 FPZ0024-001 Buzzer 1
34 FTT1030-311 3" Midrange Driver 2
35 FTW2040-311 4" Woofer 1
36 GAL0100-001 Heat Sink 1
37 GF10012-001 Fiber Washer 2
38 GSE0179-001 Transformer Bracket 1
39 GSE0185-Z01 X’former Bracket 1
40 GSE0186-001 Socket Bracket 1
41 GTN0037-001 Tuner Cover (A) 1
42 GTN0038-001 Tuner Cover (B) 1
43 IVE0075-002 3" Speaker Sponge 2
44 IVE0076-006 4" Speaker Sponge 1
45 IVE0081-001 Rubber Sponge (Left) 1
46 IVE0082-001 Rubber Spponge (Right) 1
47 BPG1027-001 GearD 2
48 BPG1039-001 Gear Rail 1
49 BPG1041-002 Gear Top 1
50 BPH0027-001 Gear Holder 1
51 DSF0007-001 Shaft (A) 1
52 DSF0008-001 Shaft (B) 1
53 GSE0173-001 Motor Bracket 1
54 FMD0004-001 Motor DC 4V 1
55 TTN1204-001 Power Transformer (120v) 1
TTN2304-001 Power Transformer (230v) 1
56 BPG1038-001 Gear Guide 1
57 BPH0029-Z03 CD Mechanism Holder 1
58 BPH003I 001 Rail Holder (Right) 1
59 BPH0032-001 Rail Holder (Left) 1
60 BPH0033-001 Turntable Holder (Left) 1
61 BPH0034-001 Turntable Holder (Right) 1
62 BPP0006-001 Pulley 4
63 BPP0007-001 Motor Pulley 1
64 BPT0012-AMO Turntable 1
65 BRF0025-001 Cushion (A) 1
66 BRF0026-001 Cushion (B) 1
67 BRF0027-001 Cushion (C) 1
68 BRW0002-001 Motor Belt 1
