JBL HARMONY - Transistor Voltage Chart

PIN NO.
REF.VOLT
P/NAME
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
IC201
5.2 5.2 5.3 5.2
IC202
2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 5.2 3.5 1.7 0 1.6
IC801
0 2.4 2 2.4 1.8 2.2 2.2 2.4
IC802
2.4 2.4 2.4 0 0 2.4 2.4 4.9 4.9 2.3 0 2.4 0 4.9 0 4.2 3.5 0 2.9 2.3
PIN NO.
REF.VOLT
P/NAME
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
IC202
5 0.3 5.3 5.2
IC802
2.4 0 0 2.4 5.2 5.2 0 4.9 2.4 2.4 4.9 4.9 2.4 2.4 0 0 2.4 2.4 0 0
TRANSISTOR VOLTAGE CHART
PART NAME
REF.VOLT
PIN NO.
Q201 Q202 Q203 Q204 Q205 Q207 Q208 Q209 Q210 Q215 Q301 Q501 Q801 Q802 Q803 Q805
E
4.73.50.907.600000001.61.71.10
C
4.7 6 6 0 7.5 1.36 0 5.3 5.3 4.4 1.2 0 1.7 0.2 1.6 0
B
4 4.2 0 0.6 6.8 0.77 0.7 0 0 0 0.1 0.6 1.6 1.6 1.1 0.7
PART NAME
REF.VOLT
PIN NO.
Q806 Q807 Q808 Q810 Q811 Q812 Q813 Q814 Q816 Q818 Q901 Q902 Q904 Q906 Q907 Q908
E
0088002.36.600.818.4 0 18.4 0.2 12 18.4
C
0 0 7.9 8 0 4 7.2 7.2 1.6 0.8 12.1 17.8 18.4 0.2 18.4 0
B
0.7 0.6 7.2 8 0.6 0 6.6 6.6 0 0.3 18.2 0.1 17.7 0.9 12.6 17.8
39
CD Player/Tuner Stereo System HARMONY
