JBL HARMONY Service Manual

5
CD Player/Tuner Stereo System HARMONY
SPECIFICATIONS
GENERAL
Power Supply
AC Line .............................230V, 50Hz (VDE)
AC Line ..............................120V, 60Hz (UL)
AC Line ............................100V, 50Hz (JAPAN)
Rated Watts................................40Watts
Auxiliary Input Impedance ..........................47kohms
Auxiliary Input Sensitivity............................500mV
Dimensions: (HxWxD)
Inches............................10-1/4 x 12-3/8 x 9-1/2”
Millimeters ...........................260x314x241mm
Weight:
Pounds .................................14-3/4 lbs
Kilograms ..................................6.6kg
FM TUNER SECTION
30dB Usable Sensitivity .............................10µV
Signal-to-Noise Ratio ..............................60dB
I-F Rejection..................................60dB
Image Rejection ................................70dB
Frequency Range ....................87.5MHz - 108MHz (VDE/UL)
Frequency Range ......................76MHz - 90MHz (JAPAN)
AM TUNER SECTION
20dB Usable Sensitivity ...........................500µV/m
Signal-to-Noise Ratio ..............................45dB
I-F Rejection..................................50dB
Image Rejection ................................30dB
AGC Figure of Merit ..............................45dB
Selectivity ...................................25dB
I-F Whistle ....................................5%
Frequency Range ...................522kHz - 1620kHz (VDE/JAPAN)
Frequency Range .......................522kHz - 1710kHz (UL)
CD SECTION
Frequency Response..........................100Hz - 20kHz
Separation (1 kHz) ..........................More than 40 dB
Signal to Noise Ratio ..............................60dB
AMPLIFIER SECTION
Power Output ................................40Watts
Power Band Width ...........................100Hz - 20kHz
Rated Impedance ..............................4Ohms
Signal to Noise Ratio AUX ...........................65dB
Equalizer Range 200Hz, 500Hz, 4kHz, 10kHz, 20kHz ..............K10 dB

JBL HARMONY Specifications

General

Brand	JBL
Model	HARMONY
Category	CD Player
Language	English
