HARMONY ELECTRICAL PARTS LIST
Main PCB Assy
Capacitors
C052J PLD3545-102 COND DISC 0.001UF 50V 10% 1
Y5P LONG LEAD
C101A PVD1335-220 COND DISC 22pF 50V 5% NPO 1
C108, C328, C339, PRA3952-101 COND ELECT 100uF 16V 20% 15
C341, C344, C354, MINI SIZE
C364, C367, C803,
C808, C816, C838,
C840, C864, C874
C109, C110, C202, PCV3955-104 CHIP CAP 0.1uF 50V 20% 20
C332, C333, C503, 1206 TYPE Y5V
C505, C802, C806,
C813, C814, C822,
C823, C824, C839,
C856, C863, C875,
C887, C889
C111, C215, C805, PCV5645-103 CHIP CAP 0.01uF 50V 10% 8
C807, C818, C820, 1206 TYPE X7R
C827, C830
C201J 047X0788012 COND MONO 0.1 uF 50V 20% Z5U 1
C203, C212, C314, PRA3955-109 COND ELECT 1uF 50V 20% 6
C315, C316, C317 MINI SIZE
C204, C205, C836, PCV1035-300 CHIP CAP 30pF 50V 5% 4
C837 1206 TYPE NPO
C206, C207 PCV1035-200 CHIP CAP 20pF 50V 5% 2
1206 TYPE NPO
C209 PRA3951-470 COND ELECT 47uF 10V 20% 1
MINI SIZE
C213 PRA3951-101 COND ELECT 100uF 10V 20% 1
MINI SIZE
C214, C363, C829, PRA3952-100 COND ELECT 10uF 16V 20% 5
C851, C852 MINI SIZE
C301, C302, C334, PCV5645-471 CHIP CAP 470pF 50V 10% 6
C335, C336, C351 1206 TYPE X7R
C303, C304, C305, PRA3955-229 COND ELECT 2.2uF 50V 20% 6
C306, C307, C308 MINI SIZE
C309, C310, C311, PRA3952-220 COND ELECT 22uF 16V 20% 4
C313 MINI SIZE
C312, C833 PCV5645-221 CHIP CAP 220pF 50V 10% 2
1206 TYPE X7R
C318, C319 PCV1035-100 CHIP CAP 10pF 50V 5% 2
1206 TYPE NPO
C320, C321, C322, PCV5635-223 CHIP CAP 0.022uF 50V 5% 4
C323 1206 TYPE X7R
C324, C325, C353 PCV5635-333 CHIP CAP 0.033uF 50V 5% 3
1206 TYPE X7R
C326 C327 PCV5635-682 CHIP CAP 0.0068uF 50V 5% 2
1206 TYPE X7R
C330, C331 PCV5635-103 CHIP CAP 0.01uF 50V 5% 2
1206 TYPE X7R
C337 C343 PCV5635-683 CHIP CAP 0.068 uF 50V 5% 2
1206 TYPE X7R
C342, C357, C358, PCV3935-104 CHIP CAP 0.1uF 50V 5% 7
C359, C360, C361 1206 TYPE Y5V
C362
C350 PCV5635-823 CHIP CAP 0.082uF 50V 5% 1
1206 TYPE X7R
C352 PCV5635-473 CHIP CAP 0.047uF 50V 5% 1
1206 TYPE X7R
C355, C356, C810, PCV5645-102 CHIP CAP 0.001uF 50V 10% 8
C815, C849, C850, 1206 TYPE X7R
C861, C862
C365 PRA3950-471 COND ELECT 470 uF 6.3V 20% 1
MINI SIZE
C366 PRA3953-100 COND ELECT 10uF 25V 20% 1
MINI SIZE
C377, C853, C891, PRA3951-221 COND ELECT 220uF 10V 20% 5
C892, C932 MINI SIZE
C501, C502 PLA3955-109 COND ELECT 1uF 50V 20% 2
LONG LEAD
C504, C801 PRA3952-470 COND ELECT 47uF 16V 20% 2
MINI SIZE
C506 PVE3953-471 COND ELECT 470uF 25V 20% D=10 1
C809, C812 PCV5645-222 CHIP CAP 0.0022uF 50V 10% 2
1206 TYPE X7R
C811, C832 PCV5645-473 CHIP CAP 0.047uF 50V 10% 2
1206 TYPE X7R
C819, C821, C826 PCV5645-333 CHIP CAP 0.033uF 50V 10% 3
1206 TYPE X7R
C825 PRA3955-479 COND ELECT 4.7uF 50V 20% 1
MINI SIZE
C828 PRA3955-108 COND ELECT 0.1uF 50V 20% 1
MINI SIZE
C834, C854 PRA3955-478 COND ELECT 0.47uF 50V 20% 2
MINI SIZE
C838A, C891A PLD3545-103 COND DISC 0.01uF 50V 10% 2
LONG LEAD
C841, C842 PCV1035-820 CHIP CAP 82pF 50V 5% 2
1206 TYPE NPO
C843, C844, C845, PCV1035-390 CHIP CAP 39pF 50V 5% 4
C846 1206 TYPE NPO
C847, C848 PCV5645-391 CHIP CAP 390pF 50V 10% 2
1206 TYPE X7R
C857, C858 PCV5645-201 CHIP CAP 200pF 50V 10% 2
1206 TYPE X7R
C873 PCV5645-223 CHIP CAP 0.022uF 50V 10% 1
1206 TYPE X7R
C890 PCV5645-152 CHIP CAP 0.0015uF 50V 10% 1
1206 TYPE X7R
C893 PRY3952-470 COND ELECT 47uF 16V 20% 1
N.P. MINI SIZE (AI)
L802 TO GND (C876) PRD3965-104 COND DISC 0.1uF 50V +80-20% 1
Y5V/Z5V
Q201C TO GND PRA3955-109 COND ELECT 1uF 50V 20% 1
MINI SIZE
TUNER PACK PRD1335-250 COND DISC 25pF 50V 5% NP0 1
TUNER PACK PARALLEL WITH C18
Connectors
CN201 CCN7879-022 CONNECTOR J.S.T. 2.0 mm PH 1
B 2B-PH-K TOP SIZE
CN202, CN903B CCN7879-030 CONNECTOR J.S.T. 2.0 mm PH 2
B10B-PH-K TOP SIZE
CN501, CN502 CCN1500-018 CONNECTOR B 2B-XH-A 2 PIN 2
POST BASE TOP
25
CD Player/Tuner Stereo System HARMONY
Ref. # Part Number Description Qty Ref. # Part Number Description Qty
