JBL HARMONY - Page 21

19
CD Player/Tuner Stereo System HARMONY
H060001-108 SCREW M1.7x0.35PxL8.0 mm 2
PAN HEAD NICKEL TO MOTOR-2
H060101-304 SCREW M2.0x0.4PxL4.0 mm 2
PAN HEAD BLACK RAIL HOLDER
R+L -4
H101001-106 SCREW T3.0x1.27p-2RHxL6.mm 4
PAN HEAD NICKEL, MOTOR BKT
TO CD HOLDER-2
H101001-108 SCREW T3.0x1.27p-2RHXL8.mm 4
PAN HEAD NICKEL PCB TO CD
MECHA HOLDER-2, HOLDER TO
T/TABLE-4, T/TABLE
HOLDER(R)(L) TO
H101001-310 SCREW T3.0x1.27p-2RHxL10mm 9
PAN HEAD BLACK, T/TABLE-4,
RCA JACK-1, CD MECHA HOLDER
TO T/TABLE-1
H101001-320 SCREW T3.0x1.27p-2RHxL20mm 1
PAN HEAD BLACK, PULLEY TO
RAIL HOLDER-2, TO T/TABLE
HOLDER-2
H101502-205 SCREW T2.6xL1.058PXL5.0 mm 4
S.BRONZE WASHER HEAD
BKT TO PCB-4
H120301-106 SCREW T3.0x0.5pxL6.0 mm 4
PAN HEAD NICKEL
GEAR GUIDE TO BKT-3
H120301-306 SCREW T3.0x0.5pxL6.0 mm 3
PAN HEAD BLACK
HEAT SINK TO CD BKT-2
H120301-308 SCREW T3.0x0.5pxL8.0 mm 2
PAN HEAD BLACK
CD LOADER WIRE DRESSING-2
IVS0007-001 FELT 100.0x10.0xT0.5 mm 2
BACK W/ADHESIVE
CD BASE HOLDER-1
IVS0009-001 FELT L130.0xW20.0xT0.5mm 1
BLK W/ADHESIVE CD
OPEN / CLOSE SW
MSV0002-001 LEVER SW MLS-1 SHINMEI 2 2
CD OPEN / CLOSE LEVER SW
TO MAIN PCB CN802
4999A-380 CON/WIRE 4 COND PIN1-2 1
120mm PIN3-4 220mm P=2.0mm
CD OPEN/CLOSE MOTOR TO
MAIN PCB CN803
4999A-381 CON/WIRE 2 COND 260 mm 1
UL1095 28 GA CD CONNECTOR
PCB CN801B TO MAIN
PCB CN801A
4999A-382 CON/WIRE 12 COND 300 mm 1
FFC 20696 1 CD CONNECTOR
PCB CN804B TO MAIN
PCB CN804A
4999A-383 CON/WIRE 6 COND 320 mm 1
FFC 20696
Gear Assy
BPG1027-001 GEAR D CU-100 2
BPG1039-001 GEAR RAIL 1
BPG1041-004 GEAR TOP W/BIGGER HOLE 1
BPH0027-001 HOLDER (GRAR) CU-100 1
DSF0008-001 SHAFT (B) 1
DSF0009-001 SHAFT GEAR SHAFT (A) 1
HARMONY (NEW)
H060201-116 SCREW M2.6x0.45PxL16.0 mm 2
PAN HEAD NICKEL
HWC4016-302 WASHER OD4.0xID1.6xT0.2 mm 1
MYLAR
HWC4020-002 WASHER OD4.0XID2.0XT0.2m 2
MYLAR
HWC5026-002 WASHER OD5.0XID2.6XT0.2mm 1
MYLAR
Ref. # Part Number Description Qty Ref. # Part Number Description Qty
