Suggested Power Amplifier DSC280 Controller Settings
DSC280 Gain Settings
Passband Amplifier Mode Power Amp Gain DSC Limiters Memory12 Memory13 Memory14 Memory15 Memory16 Memory17
JBL
HF MPA 600 Stereo 75 35 dB -2.0 dBu -8 dB -7 dB -6 dB -5 dB -5 dB -6 dB
MF MPA 1100 Bridged 400 44 dB -3.3 dBu -9 dB -6 dB -6 dB -5 dB -5 dB -8 dB
LF MPA 1100 Bridged 600 44 dB -1.6 dBu -6 dB -6 dB -4 dB -6 dB -6 dB -3 dB
Sub MPA 1100 Bridged 2 x 800 44 dB -3.3 dBu -4 dB -4 dB -4 dB -4 dB -4 dB -4 dB
HF MPX 600 Stereo 75 35 dB -2.0 dBu -8 dB -7 dB -6 dB -5 dB -5 dB -6 dB
MF MPX 1200 Bridged 400 44 dB -3.8 dBu -9 dB -6 dB -6 dB -5 dB -5 dB -8 dB
LF MPX 1200 Bridged 600 44 dB -2.0 dBu -6 dB -6 dB -4 dB -6 dB -6 dB -3 dB
Sub MPX 1200 Mono 2 x 800 38 dB -2.2 dBu -2 dB -2 dB -2 dB -2 dB -2 dB -2 dB
HF 6670 Stereo 75 32 dB -1.0dBu -5 dB -4 dB -3 dB -2 dB -2 dB -3 dB
MF 6670 Bridged 400 38 dB -2.2 dBu -3 dB -0 dB -0 dB -1 dB -1 dB -2 dB
LF 6670 Bridged 600 38 dB -4.0 dBu -0 dB -0 dB -2 dB -0 dB -0 dB -3 dB
Sub 6670 Bridged 2 x 800 38 dB -2.2 dBu -2 dB -2 dB -2 dB -2 dB -2 dB -2 dB
Crown
HF K2 Max Stereo 75 33 dB -0.1 dBu -6 dB -5 dB -4 dB -3 dB -3 dB -4 dB
MF K2 Max Bridged 400 39 dB -1.4 dBu -4 dB -1 dB -1 dB -0 dB -0 dB -3 dB
LF K2 Max Bridged 600 39 dB -3.1 dBu -1 dB -1 dB -1 dB -1 dB -1 dB -2 dB
Sub K2 Max Bridged 2 x 800 39 dB -1.4 dBu -1 dB -1 dB -1 dB -1 dB -1 dB -1 dB
.775v Sensitivity
HF M-T 2400 Stereo 75 38 dB -5.4 dBu -11 dB -10 dB -9 dB -8 dB -8 dB -9 dB
MF M-T 5000VZ Stereo 400 42 dB -2.1 dBu -7 dB -4 dB -4 dB -3 dB -3 dB -6 dB
LF M-T 5000VZ Stereo 600 37 dB 4.8 dBu -1 dB -1 dB -3 dB -1 dB -1 dB -4 dB
Sub M-T 3600VZ Mono 2 x 800 42 dB -1.6 dBu -2 dB -2 dB -2 dB -2 dB -2 dB -2 dB
1.4V Sensitivity
HF M-T 2400 Stereo 75 33 dB -0.3 dBu -6 dB -5 dB -4 dB -3 dB -3 dB -4 dB
MF M-T 5000VZ Stereo 400 37 dB -3.0 dBu -2 dB -1 dB -1 dB -2 dB -2 dB -1 dB
LF M-T 5000VZ Stereo 600 37 dB -4.8 dBu -1 dB -1 dB -3 dB -1 dB -1 dB 4 dB
Sub M-T 3600VZ Mono 2 x 800 37 dB -3.5 dBu -3 dB -3 dB -3 dB -3 dB -3 dB 3 dB
Crest
HF 7001 Stereo 75 32 dB -1.0 dBu -5 dB -4 dB -3 dB -2 dB -2 dB -3 dB
MF 9001 Stereo 400 32 dB -8.2 dBu -3 dB -6 dB -6 dB -7 dB -7 dB -4 dB
LF 9001 Bridged 600 38 dB -4.0 dBu -0 dB -0 dB -2 dB -0 dB -0 dB -3 dB
Sub 9001 Mono 2 x 800 32 dB -8 dB -8 dB -8 dB -8 dB -8 dB -8 dB -8 dB
QSC Powerlight
HF 2.0 Stereo 76 36 dB -2.9 dBu -9 dB -8 dB -7 dB -6 dB -6 dB -7 dB
MF 4.0 Stereo 400 38 dB -2.2 dBu -3 dB -0 dB -0 dB -1 dB -1 dB -2 dB
LF 8.0 Stereo 600 40 dB -1.7 dBu -2 dB -2 dB -0 dB -2 dB -2 dB -1 dB
LF 3.4 Bridged 600 44 dB -1.9 dBu -6 dB -6 dB -4 dB -6 dB -6 dB -3 dB
Sub 8.0 Mono 2 x 800 40 dB -0.0 dBu -0 dB -0 dB -0 dB -0 dB -0 dB -0 dB
Note: All calculations are based on the HLA data sheet power ratings for the drivers in each section.
