Suggested Power Amplifier DSC260 Controller Settings
DSC260 Gain Settings Gain Settings (dedicated 2nd unit required for subwoofers)
Passband Amplifier Mode Power Amp Gain DSC Limiters (Small) (2 + 1) (4 + 2) (6 + 3) (10 + 6) (12 + 6)
JBL
HF MPA 600 Stereo 75 35 dB -2.0 dBu -18 dB -17 dB -16 dB -15 dB -15 dB -16 dB
MF MPA 1100 Bridged 400 44 dB -3.3 dBu -19 dB -16 dB -16 dB -15 dB -15 dB -18 dB
LF MPA 1100 Bridged 600 44 dB -1.6 dBu -16 dB -16 dB -14 dB -16 dB -16 dB -13 dB
Sub MPA 1100 Bridged 2 x 800 44 dB -3.3 dBu -14 dB -14 dB -14 dB -14 dB -14 dB -14 dB
HF MPX 600 Stereo 75 35 dB -2.0 dBu -18 dB -17 dB -16 dB -15 dB -15 dB -16 dB
MF MPX 1200 Bridged 400 44 dB -3.8 dBu -19 dB -16 dB -16 dB -15 dB -15 dB -18 dB
LF MPX 1200 Bridged 600 44 dB -2.0 dBu -16 dB -16 dB -14 dB -16 dB -16 dB -13 dB
Sub MPX 1200 Mono 2 x 800 38 dB -2.2 dBu -18 dB -18 dB -18 dB -18 dB -18 dB -18 dB
HF 6670 Stereo 75 32 dB -1.0 dBu -15 dB -14 dB -13 dB -12 dB -12 dB -13 dB
MF 6670 Bridged 400 38 dB -2.2 dBu -13 dB -10 dB -10 dB -19 dB -19 dB -12 dB
LF 6670 Bridged 600 38 dB -4.0 dBu -10 dB -10 dB -18 dB -10 dB -10 dB -17 dB
Sub 6670 Bridged 2 x 800 38 dB -2.2 dBu -18 dB -18 dB -18 dB -18 dB -18 dB -18 dB
Crown
HF K2 Max Stereo 75 33 dB 0.1 dBu -16 dB -15 dB -14 dB -13 dB -13 dB -14 dB
MF K2 Max Bridged 400 39 dB 1.4 dBu -14 dB -11 dB -11 dB -10 dB -10 dB -13 dB
LF K2 Max Bridged 600 39 dB 3.1 dBu -11 dB -11 dB -19 dB -11 dB -11 dB -18 dB
Sub K2 Max Bridged 2 x 800 39 dB 1.4 dBu -19 dB -19 dB -19 dB -19 dB -19 dB -19 dB
.775v Sensitivity
HF M-T 2400 Stereo 75 38 dB -5.4 dBu -21 dB -20 dB -19 dB -18 dB -18 dB -19 dB
MF M-T 5000VZ Stereo 400 42 dB -2.1 dBu -17 dB -14 dB -14 dB -13 dB -13 dB -16 dB
LF M-T 5000VZ Stereo 600 37 dB -4.8 dBu -19 dB -19 dB -17 dB -19 dB -19 dB -16 dB
Sub M-T 3600VZ Mono 2 x 800 42 dB -1.6 dBu -12 dB -12 dB -12 dB -12 dB -12 dB -12 dB
1.4V Sensitivity
HF M-T 2400 Stereo 75 33 dB -0.3 dBu -16 dB -15 dB -14 dB -13 dB -13 dB -14 dB
MF M-T 5000VZ Stereo 400 37 dB -3.0 dBu -12 dB -19 dB -19 dB -18 dB -18 dB -11 dB
LF M-T 5000VZ Stereo 600 37 dB -4.8 dBu -19 dB -19 dB -17 dB -19 dB -19 dB -16 dB
Sub M-T 3600VZ Mono 2 x 800 37 dB -3.5 dBu -17 dB -17 dB -17 dB -17 dB -17 dB -17 dB
Crest
HF 7001 Stereo 75 32 dB -1.0 dBu -15 dB -14 dB -13 dB -12 dB -12 dB -13 dB
MF 9001 Stereo 400 32 dB -8.2 dBu -17 dB -14 dB -14 dB -13 dB -13 dB -16 dB
LF 9001 Bridged 600 38 dB -4.0 dBu -10 dB -10 dB -18 dB -10 dB -10 dB -17 dB
Sub 9001 Mono 2 x 800 32 dB -8 dB -12 dB -12 dB -12 dB -12 dB -v2 dB -12 dB
QSC Powerlight
HF 2.0 Stereo 76 36 dB -2.9 dBu -19 dB -18 dB -17 dB -16 dB -16 dB -17 dB
MF 4.0 Stereo 400 38 dB -2.2 dBu -13 dB -10 dB -10 dB -19 dB -19 dB -12 dB
LF 8.0 Stereo 600 40 dB -1.7 dBu -12 dB -12 dB -10 dB -12 dB -12 dB -19 dB
LF 3.4 Bridged 600 44 dB -1.9 dBu -16 dB -16 dB -14 dB -16 dB -16 dB -13 dB
Sub 8.0 Mono 2 x 800 40 dB -0.0 dBu -10 dB -10 dB -10 dB -10 dB -10 dB -10 dB
Note: All calculations based on the HLA data sheet power ratings for the drivers in each section.
