5
Typical HLA System Configuration showing controller, amplifiers and loudspeakers
HLA Series Basic Module
One Channel Shown
Output D
Output C
Output B
Output A
MPA600, Stereo mode
MPX1200, Stereo mode
MPX1200, Bridged mode
MPX1200, Bridged Mode
MPX1200, Bridged Mode
Spare Amplifier Channels to be used for additional Speakers
HF
MF
LF
JBL 4895
JBL 4897
Loop-through Connections
