6
The HLA 4895 speakers and 4897 subwoofers come standard with Neutrik NL-8 Speakon connectors.
The NL-8 Speakon connector has four pairs of speaker connections, but the two speaker models have different
circuit assignments. A different but identical speaker cable can be used for the two kinds of HLA speakers. Each
4897 sub-woofer is cabled individually to its amplifier channel. Note: only one of every four 4895 three-way
speakers must be cabled to the amplifiers. Up to three more 4895 speakers can be connected in parallel to the
first with short jumper cables. Speaker cables that will reach from the amp rack are needed for each 4895
subwoofer. Only one speaker cable that will reach from the amp rack is needed for one of every four 4895
speakers, and short jumpers are used to connect the remaining three out of four 4895 speakers together in
parallel.
