JBL LSR28P - Electronic Failure Q.A. Codes

JBL PROFESSIONAL
ELECTRONIC FAILURE
Q.A. CODES
30
July 1, 2002
Page 1
Q.A.
CODE
DESCRIPTION OF DEFECT WARRANTY
STATUS
Q.A.
CODE
DESCRIPTION OF DEFECT WARRANTY
STATUS
10.010 IC (Specify)
10.058 Capacitor - Value Changed IN
10.011 IC - Open IN 10.059 Capacitor - Broken IN
10.012 IC - Burned * OUT
10.013 IC - Shorted IN
10.060 DIODE/RECTIFIER/BRIDGE (Specify)
10.014 IC - Thermally Sensitive IN 10.061 Open IN
10.015 Noisy IN 10.062 Burned * OUT
10.016 Not Secured to Heat Sink IN 10.063 Shorted IN
10.017 IC - Wrong Part (installed at factory) IN 10.064 Thermally Sensitive IN
10.065 Wrong Part (installed at factory) IN
10.020 TRANSISTOR (Specify)
10.021 Transistor - Open IN
10.070 INDUCTOR (Specify)
10.022 Transistor - Burned * OUT 10.071 Inductor - Open IN
10.023 Transistor - Shorted IN 10.072 Inductor - Burned IN
10.024 Transistor - Thermally Sensitive IN
10.025 Transistor - Noisy IN
10.080 LED/LCD/VU METER (Specify)
10.026 Transistor - Not Secured to Heat Sink IN 10.081 No Characters/Missing IN
10.027 Transistor - Wrong Part IN 10.082 No Back Light IN
IN 10.083 Broken IN
10.030 FET (Specify)
10.084 Meter - Defective IN
10.031 FET - Open IN 10.085 Bezel - Broken IN
10.032 FET - Burned * OUT
10.033 FET - Shorted IN
10.090 RELAY (Specify)
IN
10.034 FET - Thermally Sensitive IN 10.091 Relay - Intermittent IN
10.035 FET - Noisy IN 10.092 Relay - Will Not Engage IN
10.036 FET - Not Secured to Heat Sink IN 10.093 Relay - Pitted Contacts IN
10.037 FET - Wrong Part IN IN
10.100 POTENTIOMETER (Specify)
10.040 RESISTOR (Specify)
10.101 Potentiometer - Dirty / Scratchy IN
10.041 Resistor - Open IN 10.102 Potentiometer - Open IN
10.042 Resistor - Burned * OUT 10.103 Potentiometer - Broken, Cracked IN
10.043 Resistor - Shorted IN 10.104 Potentiometer - Wrong Part (installed at factory) IN
10.044 Resistor - Thermally Sensitive IN
10.045 Resistor - Noisy IN
10.110 SWITCH (Specify)
10.046 Resistor Pack Cracked IN 10.111 Switch - Intermittent IN
10.047 Resistor - Wrong Part IN 10.112 Switch - Broken IN
10.113 Switch - Will Not Close IN
10.050 CAPACITOR (Specify)
10.114 Switch - Noisy IN
10.051 Capacitor - Open IN
10.052 Capacitor - Burned * OUT
10.120 FUSE (Specify)
10.053 Capacitor - Shorted IN 10.121 Fuse - Open IN
10.054 Capacitor - Thermally Sensitive IN 10.122 Fuse - High Resistance IN
10.055 Capacitor - Noisy IN 10.123 Fuse - Wrong IN
10.056 Capacitor - Leaky IN 10.124 Fuse - Loose IN
10.057 Capacitor - Dried Up IN
