JBL SUB333 - Sub333 Mechanical Parts List

11
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 MECHANICAL PARTS LIST
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
1 EVM0033-001 WOOD BOX 1
2 BPR0020-000 PORT EDGE 1
3 BPR0042-BA0 PORT 1
4 BPF5056-BA1 CONTROL PANEL 1
5 BNP0073-001 PVC PLATE 1
6 BPL0013-001 LOGO PLATE 1
7 BPK5031-000 CONTROL BUTTON ASSEMBLY 1
8 APE0283-001 CONTROL PCB ASSEMBLY 1
9 IVE0041-001 WOOFER GASKET 1
10 FTW6080-312 4 OHM 8' WOOFER 1
11 BRF0015-001 RUBBER PAD 4
12 BPB0012-001 BOTTOM CABINET 1
13 BRF0014-001 RUBBER PAD 4
14 IVE0042-001 BOX SPONGE 1
15 BPH0054-000 LED HOLDER 1
18 BPA0021-001 REAR COVER 1
19 APE0284-001 JACK PCB ASSEMBLY 1
20 GSE0255-001 JACK PLATE 1
21 MSV0001-004 SWITCH ROCKER 1
22 DBU0002-001 BUSHING 1
23 47455-D52 6.5 ft. AC LINE CORD 1
24 GAL0055-003 HEAT SINK 1
25 TTL1201-001 120V POWER TRANSFORMER 1
TTL2301-001 230V POWER TRANSFORMER 1
26 APE0280-001 MAIN PCB ASSEMBLY 1
27 GSE0253-001 PCB BRACKET RIGHT 1
28 GSE0254-001 PCB BRACKET LEFT 1
29 GSE0093-001 HEAT SINK BRACKET 1
30 APE0214-003 DECODER PCB ASSEMBLY 1
31 GTN0063-001 SHIELD PLATE UP 1
32 GTN0064-001 SHIELD PLATE DOWN 1
33 APE0281-001 POWER PCB ASSEMBLY 1
34 APE0282-011 DC PCB ASSEMBLY 1
35 GSE0256-001 PCB BRACKET RIGHT 1
36 GSE0257-001 PCB BRACKET LEFT 1
37 BRB0003-001 RUBBER BUSHING 1
38 BRB0004-001 RUBBER BUSHING 1
39 BRB0005-001 RUBBER BUSHING 1
N1 HNI1482 NUT @ 14x3.5 mm 4
S1 H101001-108 SCREW T3.0x1.27P 3
-2RHxL8.0 mm
S2 H016504-316 SCREW W6#-20xl16.0 mm 4
S3 H016701-316 SCREW W8#-18xL16.0 mm 8
S4 H101001-310 SCREW T3.0x1.27PxL10.0 mm 3
S5 HO60501-320 SCREW M4.0x0.7PxL20.0 mm 10
S6 H060301-314 SCREW M3.0x0.5PxL14.0 mm 2
S7 H060404-321 SCREW M3.5x0.6PxL21.0 mm 4
S8 H120301-306 SCREW M3.0x0.5PxL6.0 mm 4
S9 H041001-314 SCREW T3.0x1.27P-2RHxL14.0 2
S10 H1110022-306 SCREW T3.0x1.27P-2RHxL6.0
