Input/Output AssignmentsJBL SYNTHESIS SDEC-5500
Below shows the SDEC-5500 connections both standard and configurable when used with the
SDP-75-16
SDEC 5500 Connections
SDP-75 -16
Ouput Connections
SDEC-5500
Inputs
SDEC-5500 Outputs
IC
Cable #
SDP 75
Output #
Standard Congurable Blu-Link Channel
1 1 A1
N1 Left Full Range N1 Left Low Freq 1
X N1 Left High Freq 3
2 2 A2
N2 Right Full Range N2 Right Low Freq 2
X N2 Right High Freq 4
3 3 A3
N3 Center Full Range N3 Center Low Freq 7
X N3 Center High Freq 8
4 4 A4
N4 Side Left 10
N4 Side Left 2 (array left) 23
5 5 B1
N5 Side Right 13
N5 Side Right 2 (array right) 24
6 6 B2 N6 Rear Left 16
7 7 B3 N7 Rear Right 17
8 8 B4 N8 Sub 1, 2, 3,4 25, 26, 27,28
9 9 C1 N9 11
10 10 C2 N10 14
11 11 C3 N11 12
12 12 C4 N12 15
13 13 D1 N13 5
14 14 D2 N14 6
15 15 D3 N15 18
16 16 D4 N16 19
