JBL SYNTHESIS SDEC-4500 Input/Output Assignments
SDEC-4500 WITH BI-AMPLIFIED FRONT SPEAKERS
This configuration requires the selection of bi-amplified operation, as noted on page 6.
Surround Processor to SDEC-4500P Inputs
Number Channel SDEC-4500P
1 Left Front A1
2 Right Front A2
3 Center Front A3
4 Left Side A4
5 Right Side B1
6 Left Rear B2
7 Right Rear B3
8 Subwoofer B4
9 Left Front Height C1
10 Right Front Height C2
11 Left Rear Height C3
12 Right Rear Height C4
SDEC-4500P Outputs to Ampliers
Number Channel SDEC-4500P
13 Subwoofer 1 D1
14 Subwoofer 2 D2
15 Subwoofer 3 D3
16 Subwoofer 4 D4
SDEC-4500X Outputs to Ampliers
Number Channel SDEC-4500X
17 Left Front-Low A1
18 Left Front-Hi A2
19 Right Front-Low A3
20 Right Front-Hi A4
21 Center-Low B1
22 Center--Hi B2
23 Left Side 1 B3
24 Right Side 1 B4
25 Left Side 2 C1
26 Right Side 2 C2
27 Left Side 3/Left Rear Height C3
28 Right Side 3/Right Rear Height C4
29 Left Rear D1
30 Right Rear D2
31 Left Front Height D3
32 Right Front Height D4
