JBL SYNTHESIS SDEC-3500 Input/Output Assignments
INPuT/OuTPuT ASSIGNMENTS
SDEC-3500 ANALOG CONNECTIONS
The SDEC-3500 supports up to 7.1 input with up to 7.1 output. The input and output
assignments are described in the table below. You must make the correct connections from the
surround processor output to the amplifier input for the system to work correctly.
The correct Synthesis Interconnect kit includes all the necessary connections for using the SDEC
in the Synthesis system.
CONNECTION NOTES
Please follow the Input/Output Assignments table for correct connections.•
You will need to use the Ethernet network port on the rear panel of the unit for the final •
calibration process. You can connect the SDEC-3500 through any standard Ethernet hub.
SDEC3500 BLU LINK CHANNELS
The SDEC3500 may output digital audio via the BLU-Link output connector including 4 discrete
subwoofer channels.
SDEC-3500 INPUT/OUTPUT ASSIGNMENTS
Surround Processor to SDEC-3500 Inputs
Number Channel SDEC-3500
1 Left Front A1
2 Right Front A2
3 Center Front A3
4 Left Side A4
5 Right Side B1
6 Left Rear B2
7 Right Rear B3
8 Subwoofer B4
SDEC-3500 Outputs to Ampliers
Number Channel SDEC-3500
9 Left Front C1
10 Right Front C2
11 Center C3
12 Left Side C4
13 Right Side D1
14 Left Rear D2
15 Right Rear D3
16 Subwoofer D4
