JBL SYNTHESIS SDEC-3500/SDEC-4500/SDEC-5500 Specications
SPECIFICATIONS
INPUTS
ELECTRONICALLY BALANCED ON PHOENIX/COMBICON REMOVABLE SCREW
CONNECTORS
MIC/LINE INPUTS: NOMINAL GAIN 0DB, ELECTRONICALLY SWITCHABLE
UP TO +48DB, IN +6DB STEPS, INPUT IMPEDANCE
3.5K OHMS
MAXIMUM INPUT LEVEL: +20DBU WITH 0DB INPUT GAIN (+8DBU WITH 12DB
GAIN)
CMRR: >75DB AT 1KHZ
EQUIV. INPUT NOISE (EIN): <–128DBU TYPICAL WITH 150 OHMS SOURCE
SDEC-3500: 8 INPUTS
SDEC-4500P: 12 INPUTS
SDEC-5500: 16 INPUTS
OUTPUTS:
ELECTRONICALLY BALANCED ON PHOENIX/COMBICON REMOVABLE SCREW
CONNECTORS
MAXIMUM OUTPUT LEVEL: +19DBU
FREQUENCY RESPONSE: 20HZ – 20KHZ (+0.5/–1DB)
THD: <0.01% (20HZ – 20KHZ, +10DBU OUTPUT)
DYNAMIC RANGE: 108DB TYPICAL (22HZ – 22KHZ UNWEIGHTED)
CROSSTALK: <–75DB
SDEC-3500: 8 OUTPUTS
SDEC-4500P: 4 OUTPUTS WITH EXPANSION TO 20 WITH
SDEC-4500X OR 22 WITH SDA AMPLIFIERS
SDEC-4500X: 16 OUTPUTS
CONTROL NETWORK
BLU-Link RJ45 CONNECTOR
MAXIMUM CABLE LENGTH: 100M/300 FT. BETWEEN DEVICE AND ETHERNET
SWITCH
ETHERNET: 2 X RJ45 CONNECTORS
MAXIMUM CABLE LENGTH: 100M/300 FT. BETWEEN DEVICE AND ETHERNET
SWITCH
PANEL LED INDICATORS: SIGNAL PRESENT (PER INPUT), CLIP (PER INPUT),
SYNC/48V (PER INPUT),
LCD, CONDUCTOR ACTIVE, NET LINK ACTIVE, DATA
ACTIVITY
MAINS VOLTAGE: 85 – 270V AC, 50/60HZ
POWER CONSUMPTION: <35VA
GENERAL:
DIMENSIONS (H X W X D): 1-3/4" X 19" X 9-1/4" (44MM X 483MM X 235MM)
WEIGHT: 6.5 LB (3KG)
