BILL OF MATERIAL(MASTER P/L)
MODEL CODE: 91AM-K1000-01E
MODEL NAME: AMP-250
BUYER: JBL
DESTINATION: EUROPE
Date: 2002.03.18
ASS'Y CODE PARTS CODE DESCRIPTION SPECIFICATION Q'TY Loc. No
Ass'y Mecha
A2AMK1000A1E
DD4B00340TB0
BRIDGE RECTIFER
BU8-06
1
BR1
A2AMK1000A1E
FGFBS2002837
FUSE GLASS
2A 250V 50T
1
F101
A2AMK1000A1E
FIBA00020S6V
FUSE-COVER
L-A20
1
A2AMK1000A1E
ICRG00440SG0
IC REGULATOR
NJM7912FA TO-220
1
A2AMK1000A1E
ICRG01110SG0
IC REGULATOR
NJM7812FA 12V
1
A2AMK1000A1E
MEAC05000003
HEAT SINK-TR1
A6063 T-5
1
A2AMK1000A1E
MEAC16820004
HEAT SINK-TR2
ALP T3.0
1
A2AMK1000A1E
MJAF15420024
KNOB-ROTARY
AMP 250 ABS-720
3
A2AMK1000A1E
MJAG13060014
CORK-TERMINAL
AVR100READY ABS HF-380
8
A2AMK1000A1E
MMAC15380014
WASHER-FLAT(3.0)
A-900
10
A2AMK1000A1E
MMAC16400004
SCREW-T/P-TOOTH
3X10 BLACK
3
A2AMK1000A1E
MMAC16830004
SCREW-HEAT SINK
AK-10 CR
1
A2AMK1000A1E
MMAC16860004
SCREW-MACHINE
M3*6*PI0.5 CR WHITE
8
A2AMK1000A1E
MPAC04990012
PANEL-BACK
AMP 250 SECC T1.6 SPR
1
A2AMK1000A1E
MPAC16790004
BRACKET-VOLUME
SECC T1.0
1
A2AMK1000A1E
MPAC16800004
BRACKET-TR
SUS-304
1
A2AMK1000A1E
MPAC16810004
BRACKET-HEAT SINK
SECC T1.0
1
A2AMK1000A1E
PTAN03740YJV
POWER TRANSFORMER
A86-374Y-V(250V 50Hz)
1
A2AMK1000A1E
XNHB03000ZY0
NUT-HEXAGON
HEX-SM3*0.5 FE-ZY
1
A2AMK1000A1E
XSTB30080ZY4
SCREW-TAPPING
BHT2T 3x8 FE-ZY
9
A2AMK1000A1E
XSTB30100ZB4
SCREW-TAPPING
BHT2T 3x10 FE-ZB
2
A2AMK1000A1E
XSTB30120ZY4
SCREW-TAPPING
BHT2T 3x12 FE-ZY
1
A2AMK1000A1E
XSTB40080ZB8
SCREW-TAPPING
BHT3T 4x8 FE-ZB
4
A2AMK1000A1E
YGAP15350014
BOX-GIFT
AMP 250 DW-2 533*473*3
0.125
A2AMK1000A1E
YSAP01650001
CUSHION
EPS 530*470*195
0.25
A2AMK1000A1E
YVAP15360014
POLY-BAG
AMP 250 PE-LD 390*360*
1
A2AMK1000A1E
KDAC0012EPA8
CORD-AC
KKP-419C,KLCE-2F 2M
1
A2AMK1000A1E
777700000105
ROCKER S/W
SF-W101A-30BB
1
Ass'y Main
A2AMK1000A2E
BTEM00040470
T-FILTER
470PF 25V 6A
2
L15
A2AMK1000A2E
BTEM00040470
T-FILTER
470PF 25V 6A
2
L17
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C18
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C2
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C24
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C42
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C43
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C52
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C53
A2AMK1000A2E
CCMBF105Z0AJ
CAPACITOR CHIP/MONO
GRM42-6Y5V 105Z 25PE
8
C6
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C1
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C11
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C12
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C13
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C4
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C40
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C41
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C57
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C58
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C59
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C60
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C61
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C62
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C63
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C64
A2AMK1000A2E
CCMBJ103K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 103 50PT
16
C9
A2AMK1000A2E
CCMBJ104K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 104K 50PE
4
C16
A2AMK1000A2E
CCMBJ104K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 104K 50PE
4
C17
A2AMK1000A2E
CCMBJ104K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 104K 50PE
4
C19
A2AMK1000A2E
CCMBJ104K0AH
CAPACITOR CHIP/MONO
GRM40 X7R 104K 50PE
4
C20
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C14
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C15
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C3
1 OF 7
