JBL XTI-300 - Page 4

4/3/02
ASS'Y CODE PARTS CODE DESCRIPTION SPECIFICATION Q'TY Loc. No
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C30
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C31
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C32
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C33
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C44
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C45
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C54
A2AMK1000A2E
CCMBJ220J0AH
CAPACITOR CHIP/MONO
GRM40 COG 220J 50PT
11
C55
A2AMK1000A2E
CCMBJ222J0AH
CAPACITOR CHIP/MONO
GRM40 X7R 222K 50PT
6
C46
A2AMK1000A2E
CCMBJ222J0AH
CAPACITOR CHIP/MONO
GRM40 X7R 222K 50PT
6
C47
A2AMK1000A2E
CCMBJ222J0AH
CAPACITOR CHIP/MONO
GRM40 X7R 222K 50PT
6
C48
A2AMK1000A2E
CCMBJ222J0AH
CAPACITOR CHIP/MONO
GRM40 X7R 222K 50PT
6
C49
A2AMK1000A2E
CCMBJ222J0AH
CAPACITOR CHIP/MONO
GRM40 X7R 222K 50PT
6
C5
A2AMK1000A2E
CCMBJ222J0AH
CAPACITOR CHIP/MONO
GRM40 X7R 222K 50PT
6
R52
A2AMK1000A2E
CCMBJ331J0AH
CAPACITOR CHIP/MONO
GRM40 COG 331J 50PT
4
C21
A2AMK1000A2E
CCMBJ331J0AH
CAPACITOR CHIP/MONO
GRM40 COG 331J 50PT
4
C23
A2AMK1000A2E
CCMBJ331J0AH
CAPACITOR CHIP/MONO
GRM40 COG 331J 50PT
4
C56
A2AMK1000A2E
CCMBJ331J0AH
CAPACITOR CHIP/MONO
GRM40 COG 331J 50PT
4
C84
A2AMK1000A2E
CCMBN101J0AJ
CAPACITOR CHIP/MONO
GRM40 COG 101J 100PT
4
C25
A2AMK1000A2E
CCMBN101J0AJ
CAPACITOR CHIP/MONO
GRM40 COG 101J 100PT
4
C26
A2AMK1000A2E
CCMBN101J0AJ
CAPACITOR CHIP/MONO
GRM40 COG 101J 100PT
4
C77
A2AMK1000A2E
CCMBN101J0AJ
CAPACITOR CHIP/MONO
GRM40 COG 101J 100PT
4
C78
A2AMK1000A2E
CCMBN102K0CG
CAPACITOR CHIP
1000pF 100V X7R 10%
1
C73
A2AMK1000A2E
CCMBN103K0CG
CAPACITOR CHIP
0.01uF 100V X7R
6
C35
A2AMK1000A2E
CCMBN103K0CG
CAPACITOR CHIP
0.01uF 100V X7R
6
C36
A2AMK1000A2E
CCMBN103K0CG
CAPACITOR CHIP
0.01uF 100V X7R
6
C74
A2AMK1000A2E
CCMBN103K0CG
CAPACITOR CHIP
0.01uF 100V X7R
6
C75
A2AMK1000A2E
CCMBN103K0CG
CAPACITOR CHIP
0.01uF 100V X7R
6
C81
A2AMK1000A2E
CCMBN103K0CG
CAPACITOR CHIP
0.01uF 100V X7R
6
C82
A2AMK1000A2E
CCMBN473K0CG
CAPACITOR CHIP
0.047uF 100V X7R 10%
4
C37
A2AMK1000A2E
CCMBN473K0CG
CAPACITOR CHIP
0.047uF 100V X7R 10%
4
C39
A2AMK1000A2E
CCMBN473K0CG
CAPACITOR CHIP
0.047uF 100V X7R 10%
4
C79
A2AMK1000A2E
CCMBN473K0CG
CAPACITOR CHIP
0.047uF 100V X7R 10%
4
C80
A2AMK1000A2E
CCMBR223K0AJ
CAPACITOR CHIP/MONO
GRM42-6 X7R 223K 200PE
5
C22
A2AMK1000A2E
CCMBR223K0AJ
CAPACITOR CHIP/MONO
GRM42-6 X7R 223K 200PE
5
C38
A2AMK1000A2E
CCMBR223K0AJ
CAPACITOR CHIP/MONO
GRM42-6 X7R 223K 200PE
5
C50
A2AMK1000A2E
CCMBR223K0AJ
CAPACITOR CHIP/MONO
GRM42-6 X7R 223K 200PE
5
C51
A2AMK1000A2E
CCMBR223K0AJ
CAPACITOR CHIP/MONO
GRM42-6 X7R 223K 200PE
5
C76
A2AMK1000A2E
CEEBE470MDX1
CAPACITOR E/ALUMINUM
47uF /16V (7SC1CAB476M)
5
C10
A2AMK1000A2E
CEEBE470MDX1
CAPACITOR E/ALUMINUM
47uF /16V (7SC1CAB476M)
5
C65
A2AMK1000A2E
CEEBE470MDX1
CAPACITOR E/ALUMINUM
47uF /16V (7SC1CAB476M)
5
C66
A2AMK1000A2E
CEEBE470MDX1
CAPACITOR E/ALUMINUM
47uF /16V (7SC1CAB476M)
5
C67
A2AMK1000A2E
CEEBE470MDX1
CAPACITOR E/ALUMINUM
47uF /16V (7SC1CAB476M)
5
C68
A2AMK1000A2E
CEETG471MHN4
CAPACITOR E/ALUMINUM
470uF/35v(1SG1VWM477M)
2
C69
A2AMK1000A2E
CEETG471MHN4
CAPACITOR E/ALUMINUM
470uF/35v(1SG1VWM477M)
2
C70
A2AMK1000A2E
CEETM222MPS1
CAPACITOR E/ALUMINUM
2200UF/80V(3HE1KVB228MHA)
3
C27
A2AMK1000A2E
CEETM222MPS1
CAPACITOR E/ALUMINUM
2200UF/80V(3HE1KVB228MHA)
3
C28
A2AMK1000A2E
CEETM222MPS1
CAPACITOR E/ALUMINUM
2200UF/80V(3HE1KVB228MHA)
3
C29
A2AMK1000A2E
CFMSJ684KKC0
MMK CAPACITOR
680NF 100V 10%
1
C34
A2AMK1000A2E
DDBP00010VX0
DUAL DIODE
BAV70(SMT)
4
D1
A2AMK1000A2E
DDBP00010VX0
DUAL DIODE
BAV70(SMT)
4
D2
A2AMK1000A2E
DDBP00010VX0
DUAL DIODE
BAV70(SMT)
4
D4
A2AMK1000A2E
DDBP00010VX0
DUAL DIODE
BAV70(SMT)
4
D5
A2AMK1000A2E
DD4B00350TB0
BRIDGE RECTIFER
DF01S(SMT)
1
BR2
A2AMK1000A2E
DPLT00821RR3
DOT-LED
LTL-1CHP RED R3.1
1
D3
A2AMK1000A2E
ICCM01530VX0
RETIG TIMER IC
MM74HC123AM
1
U16
A2AMK1000A2E
ICCM01540T20
AND GATE IC
74VHC08M
1
U5
A2AMK1000A2E
ICCM01550VX0
EX-OR GATE IC
74AC86SC
1
U6
A2AMK1000A2E
ICCM01560VX0
SCHMITT TRIGGER IC
74VHC132M
1
U4
A2AMK1000A2E
ICHY00390TS0
H-BRIDGE DROVER IC
HIP2100IB
2
U8
A2AMK1000A2E
ICHY00390TS0
H-BRIDGE DROVER IC
HIP2100IB
2
U9
A2AMK1000A2E
ICHY00410W70
EQUILOG MODULATOR
EQ 805
1
U11
A2AMK1000A2E
ICOP03200TC0
OP-AMP IC
MC33079DR2
1
U10
A2AMK1000A2E
ICOP03300T20
COMPARATOR IC
LM393MX
1
U1
A2AMK1000A2E
ICRG01070TC0
5V REGULATOR
MC78L05ACDR2
1
U13
A2AMK1000A2E
ICRG01080TC0
-5V REGULATOR
MC79L05ACD(SMD)
1
U15
A2AMK1000A2E
ICTT00430S70
INVERTER IC
N74F07AD
1
U7
A2AMK1000A2E
KIBK00310EH0
DUAL INDUCTOR
30uH 10A
1
L20
2 OF 7
