JBL XTI-300 - Page 5

4/3/02
ASS'Y CODE PARTS CODE DESCRIPTION SPECIFICATION Q'TY Loc. No
A2AMK1000A2E
KNCW009705T9
CONNECTOR-WAFER
JE202-1T-5P
1
ST1
A2AMK1000A2E
KORB00120C00
FERRIT BEAD
BL01RN1-A62-001
3
L1
A2AMK1000A2E
KORB00120C00
FERRIT BEAD
BL01RN1-A62-001
3
L2
A2AMK1000A2E
KORB00120C00
FERRIT BEAD
BL01RN1-A62-001
3
L5
A2AMK1000A2E
KORI00020000
AORCORE INDUCTOR
75nH
4
L3
A2AMK1000A2E
KORI00020000
AORCORE INDUCTOR
75nH
4
L4
A2AMK1000A2E
KORI00020000
AORCORE INDUCTOR
75nH
4
L6
A2AMK1000A2E
KORI00020000
AORCORE INDUCTOR
75nH
4
L7
A2AMK1000A2E
PCSA053101KB
PCB-(EPOXY 4 LAYER)
A1A-531,FR2(100x100x1.6t)
1
A2AMK1000A2E
RCPBBX009520
CHIP RESISTOR(SMT)
681 50PPM 0.1% (MMA0204)
2
R36
A2AMK1000A2E
RCPBBX009520
CHIP RESISTOR(SMT)
681 50PPM 0.1% (MMA0204)
2
R38
A2AMK1000A2E
RCPBBX010Z22
RESISTOR-CHIP C/FILM
33.2k 1/10W 1% B
2
R3
A2AMK1000A2E
RCPBBX010Z22
RESISTOR-CHIP C/FILM
33.2k 1/10W 1% B
2
R53
A2AMK1000A2E
RCPBB000J21C
RESISTOR-CHIP C/FILM
0ohm 1/10W 5% B
3
R76
A2AMK1000A2E
RCPBB000J21C
RESISTOR-CHIP C/FILM
0ohm 1/10W 5% B
3
R80
A2AMK1000A2E
RCPBB000J21C
RESISTOR-CHIP C/FILM
0ohm 1/10W 5% B
3
R82
A2AMK1000A2E
RCPBB102F21C
RESISTOR-CHIP C/FILM
1Kohm 1% CHIP
1
R54
A2AMK1000A2E
RCPBB103F21C
RESISTOR-CHIP C/FILM
10Kohm 1/10W 1% B
6
R1
A2AMK1000A2E
RCPBB103F21C
RESISTOR-CHIP C/FILM
10Kohm 1/10W 1% B
6
R11
A2AMK1000A2E
RCPBB103F21C
RESISTOR-CHIP C/FILM
10Kohm 1/10W 1% B
6
R16
A2AMK1000A2E
RCPBB103F21C
RESISTOR-CHIP C/FILM
10Kohm 1/10W 1% B
6
R6
A2AMK1000A2E
RCPBB103F21C
RESISTOR-CHIP C/FILM
10Kohm 1/10W 1% B
6
R61
A2AMK1000A2E
RCPBB103F21C
RESISTOR-CHIP C/FILM
10Kohm 1/10W 1% B
6
R8
A2AMK1000A2E
RCPBB104F21C
RESISTOR-CHIP C/FILM
100K 1/10W 1% B
5
R39
A2AMK1000A2E
RCPBB104F21C
RESISTOR-CHIP C/FILM
100K 1/10W 1% B
5
R40
A2AMK1000A2E
RCPBB104F21C
RESISTOR-CHIP C/FILM
100K 1/10W 1% B
5
R5
A2AMK1000A2E
RCPBB104F21C
RESISTOR-CHIP C/FILM
100K 1/10W 1% B
5
R58
A2AMK1000A2E
RCPBB104F21C
RESISTOR-CHIP C/FILM
100K 1/10W 1% B
5
R78
A2AMK1000A2E
RCPBB105J21C
RESISTOR-CHIP C/FILM
1Mohm 1/10W 5% B
1
R4
A2AMK1000A2E
RCPBB150F21C
RESISTOR-CHIP C/FILM
15ohm 1/10W 1% B
4
R22
A2AMK1000A2E
RCPBB150F21C
RESISTOR-CHIP C/FILM
15ohm 1/10W 1% B
4
R23
A2AMK1000A2E
RCPBB150F21C
RESISTOR-CHIP C/FILM
15ohm 1/10W 1% B
4
R24
A2AMK1000A2E
RCPBB150F21C
RESISTOR-CHIP C/FILM
15ohm 1/10W 1% B
4
R25
A2AMK1000A2E
RCPBB151F21C
RESISTOR-CHIP C/FILM
150ohm 1% CHIP
1
R74
A2AMK1000A2E
RCPBB182F21C
RESISTOR-CHIP C/FILM
1.8K 1% 1/10W chip
1
R70
A2AMK1000A2E
RCPBB203F21C
RESISTOR-CHIP C/FILM
20Kohm 1/10W 1% B
2
R12
A2AMK1000A2E
RCPBB203F21C
RESISTOR-CHIP C/FILM
20Kohm 1/10W 1% B
2
R69
A2AMK1000A2E
RCPBB221F21C
RESISTOR-CHIP C/FILM
220R 1% 1/10W chip
4
R43
A2AMK1000A2E
RCPBB221F21C
RESISTOR-CHIP C/FILM
220R 1% 1/10W chip
4
R44
A2AMK1000A2E
RCPBB221F21C
RESISTOR-CHIP C/FILM
220R 1% 1/10W chip
4
R45
A2AMK1000A2E
RCPBB221F21C
RESISTOR-CHIP C/FILM
220R 1% 1/10W chip
4
R46
A2AMK1000A2E
RCPBB224J21C
RESISTOR-CHIP C/FILM
220Kohm 1/10W 5% B
1
R2
A2AMK1000A2E
RCPBB242F21C
RESISTOR-CHIP C/FILM
2.4Kohm 1/10W 1% B
2
R20
A2AMK1000A2E
RCPBB242F21C
RESISTOR-CHIP C/FILM
2.4Kohm 1/10W 1% B
2
R21
A2AMK1000A2E
RCPBB283F21C
RESISTOR-CHIP C/FILM
28Kohm 1/10W 1% B
1
R34
A2AMK1000A2E
RCPBB331F21C
RESISTOR-CHIP C/FILM
330R 1% 1/10W chip
2
R48
A2AMK1000A2E
RCPBB331F21C
RESISTOR-CHIP C/FILM
330R 1% 1/10W chip
2
R50
A2AMK1000A2E
RCPBB332F21C
RESISTOR-CHIP C/FILM
3.3K 1/10W 1% B
1
R7
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R10
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R17
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R41
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R42
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R56
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R57
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R59
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R60
A2AMK1000A2E
RCPBB472F21C
RESISTOR-CHIP C/FILM
4.7K 1% 1/10W chip
9
R9
A2AMK1000A2E
RCPBB560F21C
RESISTOR-CHIP C/FILM
56R 1% 1/10W chip
2
R15
A2AMK1000A2E
RCPBB560F21C
RESISTOR-CHIP C/FILM
56R 1% 1/10W chip
2
R34
A2AMK1000A2E
RCPBF103F520
CHIP RESISTOR(SMT)
10K 50ppm 0.1% (MMA0204)
2
R35
A2AMK1000A2E
RCPBF103F520
CHIP RESISTOR(SMT)
10K 50ppm 0.1% (MMA0204)
2
R37
A2AMK1000A2E
RCPBF120F520
CHIP RESISTOR(SMT)
12R 50ppm 1%(SSM0204 MELF)
2
R26
A2AMK1000A2E
RCPBF120F520
CHIP RESISTOR(SMT)
12R 50ppm 1%(SSM0204 MELF)
2
R27
A2AMK1000A2E
RCPBF3R0F520
CHIP RESISTOR(SMT)
3R 50ppm 1%(SSM0204 MELF)
6
R28
A2AMK1000A2E
RCPBF3R0F520
CHIP RESISTOR(SMT)
3R 50ppm 1%(SSM0204 MELF)
6
R29
A2AMK1000A2E
RCPBF3R0F520
CHIP RESISTOR(SMT)
3R 50ppm 1%(SSM0204 MELF)
6
R64
A2AMK1000A2E
RCPBF3R0F520
CHIP RESISTOR(SMT)
3R 50ppm 1%(SSM0204 MELF)
6
R65
A2AMK1000A2E
RCPBF3R0F520
CHIP RESISTOR(SMT)
3R 50ppm 1%(SSM0204 MELF)
6
R66
3 OF 7
