JBL XTI-300 - Page 6

4/3/02
ASS'Y CODE PARTS CODE DESCRIPTION SPECIFICATION Q'TY Loc. No
A2AMK1000A2E
RCPBF3R0F520
CHIP RESISTOR(SMT)
3R 50ppm 1%(SSM0204 MELF)
6
R67
A2AMK1000A2E
RCPBF682F520
CHIP RESISTOR(SMT)
6K8 50ppm 1%(SSM0204 MELF)
2
R47
A2AMK1000A2E
RCPBF682F520
CHIP RESISTOR(SMT)
6K8 50ppm 1%(SSM0204 MELF)
2
R49
A2AMK1000A2E
RCPBH1R0F620
CHIP RESISTOR(SMT)
1R0 50ppm 1%(SSM0207 MELF)
4
R30
A2AMK1000A2E
RCPBH1R0F620
CHIP RESISTOR(SMT)
1R0 50ppm 1%(SSM0207 MELF)
4
R31
A2AMK1000A2E
RCPBH1R0F620
CHIP RESISTOR(SMT)
1R0 50ppm 1%(SSM0207 MELF)
4
R32
A2AMK1000A2E
RCPBH1R0F620
CHIP RESISTOR(SMT)
1R0 50ppm 1%(SSM0207 MELF)
4
R33
A2AMK1000A2E
TRBA01770TC0
TR
MMBT2222ALT1(SMT)
4
Q3
A2AMK1000A2E
TRBA01770TC0
TR
MMBT2222ALT1(SMT)
4
Q5
A2AMK1000A2E
TRBA01770TC0
TR
MMBT2222ALT1(SMT)
4
Q7
A2AMK1000A2E
TRBA01770TC0
TR
MMBT2222ALT1(SMT)
4
Q9
A2AMK1000A2E
TRBC01950TC0
TRANSISTOR
MMBT2907ALT1(SMT)
4
Q10
A2AMK1000A2E
TRBC01950TC0
TRANSISTOR
MMBT2907ALT1(SMT)
4
Q4
A2AMK1000A2E
TRBC01950TC0
TRANSISTOR
MMBT2907ALT1(SMT)
4
Q6
A2AMK1000A2E
TRBC01950TC0
TRANSISTOR
MMBT2907ALT1(SMT)
4
Q8
A2AMK1000A2E
TRSK00270W20
MOSFER(100V)
IRFI540N
4
Q11
A2AMK1000A2E
TRSK00270W20
MOSFER(100V)
IRFI540N
4
Q12
A2AMK1000A2E
TRSK00270W20
MOSFER(100V)
IRFI540N
4
Q14
A2AMK1000A2E
TRSK00270W20
MOSFER(100V)
IRFI540N
4
Q15
A2AMK1000A2E
KNCW0201008T
WAFER
LW0640-08
1
ST2
A2AMK1000A2E
KNCW0202001T
WAFER
35718-4410
1
J2
A2AMK1000A2E
KNCW0203001T
WAFER
35725-4410
1
J1
Ass'y Front
A2AMK1000A3E
CCATF103ZAAF
CAPACITOR CERAMIC
0.01uF Z 25V F T
4
C103
A2AMK1000A3E
CCATF103ZAAF
CAPACITOR CERAMIC
0.01uF Z 25V F T
4
C105
A2AMK1000A3E
CCATF103ZAAF
CAPACITOR CERAMIC
0.01uF Z 25V F T
4
C25
A2AMK1000A3E
CCATF103ZAAF
CAPACITOR CERAMIC
0.01uF Z 25V F T
4
C30
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C10
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C15
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C16
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C17
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C20
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C22
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C26
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C31
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C32
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C33
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C34
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C4
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C5
A2AMK1000A3E
CCATJ102KAAB
CAPACITOR CERAMIC
1000PF K 50V B T
14
C8
A2AMK1000A3E
CCATJ104ZAAF
CAPACITOR CERAMIC
0.1uF Z 50V F T
2
C115
A2AMK1000A3E
CCATJ104ZAAF
CAPACITOR CERAMIC
0.1uF Z 50V F T
2
C116
A2AMK1000A3E
CCATJ220JAAZ
CAPACITOR CERAMIC
22PF J 50V SL T
1
C35
A2AMK1000A3E
CCATJ330JAAZ
CAPACITOR CERAMIC
33PF J 50V SL T
2
C1
A2AMK1000A3E
CCATJ330JAAZ
CAPACITOR CERAMIC
33PF J 50V SL T
2
C29
A2AMK1000A3E
CEETE101MDI0
CAPACITOR E/ALUMINUM
100uF M 16V 6.3x11 T
1
C118
A2AMK1000A3E
CEETF220MCI0
CAPACITOR E/ALUMINUM
22uF M 25V 5x11 T
1
C101
A2AMK1000A3E
CEETF470MCI0
CAPACITOR E/ALUMINUM
47uF M 25V 5x11 T
4
C102
A2AMK1000A3E
CEETF470MCI0
CAPACITOR E/ALUMINUM
47uF M 25V 5x11 T
4
C104
A2AMK1000A3E
CEETF470MCI0
CAPACITOR E/ALUMINUM
47uF M 25V 5x11 T
4
C106
A2AMK1000A3E
CEETF470MCI0
CAPACITOR E/ALUMINUM
47uF M 25V 5x11 T
4
C107
A2AMK1000A3E
CEETJ1R0MCI0
CAPACITOR E/ALUMINUM
1.0uF M 50V 5x11 T
1
C108
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C117
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C18
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C19
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C24
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C6
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C7
A2AMK1000A3E
CEETJ100MCI0
CAPACITOR E/ALUMINUM
10uF M 50V 5x11 T
7
C9
A2AMK1000A3E
CFMTJ474JDF0
CAPACITOR F/POLYESTR
0.47uF J 50V 6x8 TL
3
C201
A2AMK1000A3E
CFMTJ474JDF0
CAPACITOR F/POLYESTR
0.47uF J 50V 6x8 TL
3
C27
A2AMK1000A3E
CFMTJ474JDF0
CAPACITOR F/POLYESTR
0.47uF J 50V 6x8 TL
3
C28
A2AMK1000A3E
CFMTL224JEF0
CAPACITOR F/POLYESTR
0.22uF J 63V 7.5x8.5 TL
2
C12
A2AMK1000A3E
CFMTL224JEF0
CAPACITOR F/POLYESTR
0.22uF J 63V 7.5x8.5 TL
2
C14
A2AMK1000A3E
CFMTL684JFI0
CAPACITOR F/POLYESTR
0.68uF J 63V 8x11.5 TL
2
C2
A2AMK1000A3E
CFMTL684JFI0
CAPACITOR F/POLYESTR
0.68uF J 63V 8x11.5 TL
2
C3
A2AMK1000A3E
CFMTN154JHH0
CAPACITOR F/POLYESTR
0.15uF J 100V 10.3x9.8 T
1
C23
4 OF 7
