JBL XTI-300 - Page 7

4/3/02
ASS'Y CODE PARTS CODE DESCRIPTION SPECIFICATION Q'TY Loc. No
A2AMK1000A3E
CFMTN223JEK0
CAPACITOR F/POLYESTR
0.022uF J 100V 7.4x13 T
2
C11
A2AMK1000A3E
CFMTN223JEK0
CAPACITOR F/POLYESTR
0.022uF J 100V 7.4x13 T
2
C13
A2AMK1000A3E
CFTTJ104JEC0
CAPACITOR F/TF
0.1uF J 50V ECQ-V1H104JL3
1
C21
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D1
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D2
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D201
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D202
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D203
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D204
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D205
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D206
A2AMK1000A3E
DDTS00070SO0
DIODE-SI
1SS133 (40V 0.11A) DO-40 T
9
D3
A2AMK1000A3E
DPLT00840MG3
DOT-LED
LTL-1CHG GRN R3.1
1
LD1
A2AMK1000A3E
ICOP03310TV0
IC OP AMP
TL074ACD
2
U1
A2AMK1000A3E
ICOP03310TV0
IC OP AMP
TL074ACD
2
U2
A2AMK1000A3E
KNCW002402T9
CONNECTOR-WAFER
53014-02 2.0mm WHT
1
CH104
A2AMK1000A3E
KNCW009902T9
CONNECTOR-WAFER
JE202A-1T-02
2
CN101
A2AMK1000A3E
KNCW009902T9
CONNECTOR-WAFER
JE202A-1T-02
2
CN102
A2AMK1000A3E
MPAC11620004
FUSE CLIP
5.2Pi TAPPING TYPE
2
FC101
A2AMK1000A3E
MPAC11620004
FUSE CLIP
5.2Pi TAPPING TYPE
2
FC102
A2AMK1000A3E
MRAG13710004
SUPPORT-LED
RUBBER 12.7m/m
1
A2AMK1000A3E
PCSA0532011B
PCB
A1A-532,FR1(247x247x1.6t)
1
PCB1
A2AMK1000A3E
RCFTE102J000
RESISTOR-CARBON FILM
1Kohm 1/5W 5% T
1
R202
A2AMK1000A3E
RCFTE103J000
RESISTOR-CARBON FILM
10Kohm 1/5W 5% T
5
R110
A2AMK1000A3E
RCFTE103J000
RESISTOR-CARBON FILM
10Kohm 1/5W 5% T
5
R114
A2AMK1000A3E
RCFTE103J000
RESISTOR-CARBON FILM
10Kohm 1/5W 5% T
5
R15
A2AMK1000A3E
RCFTE103J000
RESISTOR-CARBON FILM
10Kohm 1/5W 5% T
5
R18
A2AMK1000A3E
RCFTE103J000
RESISTOR-CARBON FILM
10Kohm 1/5W 5% T
5
R20
A2AMK1000A3E
RCFTE222J000
RESISTOR-CARBON FILM
2.2Kohm 1/5W 5% T
1
R107
A2AMK1000A3E
RCFTE223J000
RESISTOR-CARBON FILM
22Kohm 1/5W 5% T
2
R26
A2AMK1000A3E
RCFTE223J000
RESISTOR-CARBON FILM
22Kohm 1/5W 5% T
2
R33
A2AMK1000A3E
RCFTE271J000
RESISTOR-CARBON FILM
270ohm 1/5W 5% T
1
R201
A2AMK1000A3E
RCFTE272J000
RESISTOR-CARBON FILM
2.7Kohm 1/5W 5% T
3
R11
A2AMK1000A3E
RCFTE272J000
RESISTOR-CARBON FILM
2.7Kohm 1/5W 5% T
3
R6
A2AMK1000A3E
RCFTE272J000
RESISTOR-CARBON FILM
2.7Kohm 1/5W 5% T
3
R7
A2AMK1000A3E
RCFTE273J000
RESISTOR-CARBON FILM
27Kohm 1/5W 5% T
2
R25
A2AMK1000A3E
RCFTE273J000
RESISTOR-CARBON FILM
27Kohm 1/5W 5% T
2
R5
A2AMK1000A3E
RCFTE393J000
RESISTOR-CARBON FILM
39Kohm 1/5W 5% T
1
R30
A2AMK1000A3E
RCFTE433J000
RESISTOR-CARBON FILM
43Kohm 1/5W 5% T
1
R24
A2AMK1000A3E
RCFTE470J000
RESISTOR-CARBON FILM
47ohm 1/5W 5% T
4
R102
A2AMK1000A3E
RCFTE470J000
RESISTOR-CARBON FILM
47ohm 1/5W 5% T
4
R103
A2AMK1000A3E
RCFTE470J000
RESISTOR-CARBON FILM
47ohm 1/5W 5% T
4
R104
A2AMK1000A3E
RCFTE470J000
RESISTOR-CARBON FILM
47ohm 1/5W 5% T
4
R105
A2AMK1000A3E
RCFTE472J000
RESISTOR-CARBON FILM
4.7Kohm 1/5W 5% T
5
R106
A2AMK1000A3E
RCFTE472J000
RESISTOR-CARBON FILM
4.7Kohm 1/5W 5% T
5
R108
A2AMK1000A3E
RCFTE472J000
RESISTOR-CARBON FILM
4.7Kohm 1/5W 5% T
5
R109
A2AMK1000A3E
RCFTE472J000
RESISTOR-CARBON FILM
4.7Kohm 1/5W 5% T
5
R34
A2AMK1000A3E
RCFTE472J000
RESISTOR-CARBON FILM
4.7Kohm 1/5W 5% T
5
R35
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R111
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R17
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R22
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R28
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R29
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R3
A2AMK1000A3E
RCFTE473J000
RESISTOR-CARBON FILM
47Kohm 1/5W 5% T
7
R4
A2AMK1000A3E
RCFTE474J000
RESISTOR-CARBON FILM
470Kohm 1/5W 5% T
4
R12
A2AMK1000A3E
RCFTE474J000
RESISTOR-CARBON FILM
470Kohm 1/5W 5% T
4
R16
A2AMK1000A3E
RCFTE474J000
RESISTOR-CARBON FILM
470Kohm 1/5W 5% T
4
R19
A2AMK1000A3E
RCFTE474J000
RESISTOR-CARBON FILM
470Kohm 1/5W 5% T
4
R21
A2AMK1000A3E
RCFTE513J000
RESISTOR-CARBON FILM
51Kohm 1/5W 5% T
1
R27
A2AMK1000A3E
RCFTE562J000
RESISTOR-CARBON FILM
5.6Kohm 1/5W 5% T
4
R10
A2AMK1000A3E
RCFTE562J000
RESISTOR-CARBON FILM
5.6Kohm 1/5W 5% T
4
R112
A2AMK1000A3E
RCFTE562J000
RESISTOR-CARBON FILM
5.6Kohm 1/5W 5% T
4
R113
A2AMK1000A3E
RCFTE562J000
RESISTOR-CARBON FILM
5.6Kohm 1/5W 5% T
4
R23
A2AMK1000A3E
RCFTE563J000
RESISTOR-CARBON FILM
56Kohm 1/5W 5% T
1
R31
A2AMK1000A3E
RCFTE683J000
RESISTOR-CARBON FILM
68Kohm 1/5W 5% T
3
R1
A2AMK1000A3E
RCFTE683J000
RESISTOR-CARBON FILM
68Kohm 1/5W 5% T
3
R14
A2AMK1000A3E
RCFTE683J000
RESISTOR-CARBON FILM
68Kohm 1/5W 5% T
3
R9
5 OF 7
