JBL XTI-300 - Page 8

4/3/02
ASS'Y CODE PARTS CODE DESCRIPTION SPECIFICATION Q'TY Loc. No
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW1
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW14
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW15
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW16
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW17
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW18
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW19
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW2
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW20
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW21
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW22
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW23
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW24
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW25
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW26
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW27
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW28
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW29
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW30
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW31
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW32
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW33
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW34
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW35
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW36
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW37
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW38
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW39
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW4
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW40
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW5
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW6
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW7
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW8
A2AMK1000A3E
RJWT00000AA0
RESISTOR-JUMPER WIRE
60mm-TX123 F
35
JW9
A2AMK1000A3E
SKAO00220C50
AC POWER SOCKET
HJC-028
1
AC101
A2AMK1000A3E
SKRC00400041
SOCKET-RCA
JK0400450N
1
J1
A2AMK1000A3E
SWSL01000098
SLIDE SWITCH
SSAF122NB
1
SW102
A2AMK1000A3E
TESP0046008S
TERMINAL SPEAKER
SH0810361P 8P
1
J2
A2AMK1000A3E
TRTA0008YSD0
TRANSISTOR P-H FREQ
KTA1266-Y TO92
1
Q106
A2AMK1000A3E
TRTA00940SD0
TRANSISTOR P-H FREQ
KRA107M W/RESIST TO92M
3
Q101
A2AMK1000A3E
TRTA00940SD0
TRANSISTOR P-H FREQ
KRA107M W/RESIST TO92M
3
Q104
A2AMK1000A3E
TRTA00940SD0
TRANSISTOR P-H FREQ
KRA107M W/RESIST TO92M
3
Q105
A2AMK1000A3E
TRTD00200SD0
TRANSISTOR N-L FREQ
KTD-1302 TO92
2
Q102
A2AMK1000A3E
TRTD00200SD0
TRANSISTOR N-L FREQ
KTD-1302 TO92
2
Q103
A2AMK1000A3E
U20811713250
WIRE-ASS'Y
UL1007#26 BRN-130
1
A2AMK1000A3E
U3629B312480
WIRE-ASS'Y
UL1618#18 WHT 120 3P
1
A2AMK1000A3E
U82971613200
WIRE-ASS'Y
UL1007#24 VIT-130
1
A2AMK1000A3E
CACSS472M200
CAPACITOR AC
KH DE1310E 472M 250V P10mm
1
C114
A2AMK1000A3E
VRDED024B103
V/R RK09 10KB*4
RK0971410-10KBx4
1
VR101
A2AMK1000A3E
VRDED025A503
V/R RK09 50KA
RK0971110-50KA
2
VR201
A2AMK1000A3E
VRDED025A503
V/R RK09 50KA
RK0971110-50KA
2
VR301
Ass'y Sub
A2AMK1000AZE
ZBNG007004ZL
BOND-ADHESIVE
#575
0.5
A2AMK1000AZE
ZSBR00010060
SOLDER-BAR
SN60
15
A2AMK1000AZE
ZSWR00010F60
SOLDER-WIRE
D1.0 SN60
15
#
A2AMK1000AZE
ZZFX00010000
FLUX
ROSIN 28
7
#
A2AMK1000AZE
ZZTH00010000
DILUENT
ROSIN
2
A2AMK1000AZE
ZBNG004000ZL
BOND-ADHESIVE
SC-306
0.5
6 OF 7
