jcb 1T-2 High Tip - Lighting Control Functions

12 Please see operator manual for full details.
Layout & controls
Road lights
1 = Off
2 = On (Sidelights and headlights)
3 = On (Sidelights only)
Hazard warning lights
1 = Off
2 = On (a light on the
instrument panel flashes
with the outside lights)
Work lights
1 = Off
2 = On
Fig 10
Fig 11 Fig 12
A Forwards – Left turn
B Backwards – Right turn
C Rotate – Headlights flash,
high beam and low beam
D Push – Horn
1 Headlights flash
2 High beam
3 Low beam
B Light bar
1
2
3
A
B
