jcb 1T-2 High Tip User Manual

1T-2 High Tip Site Dumper 13
Fig 15
Layout & controls
Fig 13
A Battery charging condition
B Engine oil temperature
C Engine oils pressure
D Hydraulic oil temperature
E Engine pre-heat
F Main-beam lights
G Park brake
H Direction indicators
J Engine intake air filter
K Neutral
L Fuel level indicator
M Hour meter
A Raise dumper skip lever
B Tip dumper skip lever
C Pull
D Push
Fig 14
Push this pedal down to increase engine speed. Let the pedal up
to reduce engine speed. With your foot off the pedal the engine
will idle. When drive is selected push the pedal to increase travel
speed. The machine brakes are hydraulically operated and applied
automatically when you release the pedal.
A
B
C
D
D
C
A
G
C
J
E
B
F
D
H
L
K
M
