Section 3-3 - Routine Maintenance
Service Schedules - Machines with SE Engines
Introduction
3-3-6 3-3-6
9803/3750-05 (3-21-00)
Functional Test and Final Inspection
Operation 10 50
100
(1)
500 1000 2000 8000
ENGINE
Idle Speed
(2)
- Check and Adjust

Torque Converter Stall Speed
(2)
- Check

Max. No-Load Speed
(2)
- Check and Adjust

Exhaust System Security
(2)
- Check

Air Inlet System Security - Check

TRANSMISSION, AXLES AND
STEERING
Steering - Operation/Phasing - Check

2WD/4WD Selection (if fitted) - Check

Transmission Operation - Check

Forward/Reverse/Gear - Selection/
Operation
- Check

Torque Converter Main Line Pressure
(2)
- Check

Neutral Start Operation - Check

Clutch Disconnect/Dump Button - Check

HYDRAULICS
MRV Pressure at Max RPM
(2)
- Check and Adjust

Operation of All Services - Check

Hose Burst Protection Valves (if fitted) - Check

ARV Pressure at 750 RPM
(2)
- Check and Adjust

Steer Circuit MRV Pressure
(2)
- Check and Adjust

Fan Motor Speed (If fitted)
(2)
- Check

Attachment Operation/Remote Servo (if
fitted)
- Check

Piston Rods Chrome - Check

Boom Extension/Phasing (3 stage
boom)
(2)
- Check

Parallel Lift/Lower - Check

Stabiliser Leg Cut-out (if fitted)
(2)
- Check

Chassis Levelling (Sway) Cut-out (if
fitted)
(2)
- Check

