Section 1-5 - General Information
Service Tools
Tool Detail Reference
1-5-16 1-5-16
9803/3750-05 (1-06-00)
Fig 40. 892/00964 Test Point 1/8 BSP Fig 41. 892/00965 Test Point 3/8 BSP
Fig 42. Hand Pump Equipment
892/00223 Hand Pump
892/00137 Micro-bore Hose 1/4 in BSP x 3 metres
892/00274 Adapter 1/4 in M BSP x 3/8 in M BSP Taper
892/00262 1/4 in M BSP x 1/4 in F BSP x Test Point
892/00706 Test Probe
892/00278
Gauge 0 - 40 bar (0 - 600 lbf/in
2
)
892/00279
Gauge 0 - 400 bar (0 - 6000 lbf/in
2
)
Fig 43. 892/00881 Valve Spool Seal Fitting Tool
Fig 44. 892/00229 Flow Meter
TBA
Fig 45. 892/01268 Digital Pressure Gauge 0-400 bar
892/01271 Hose for pressure gauge
C068360
