Section 1-5 - General Information
Service Tools
Tool Detail Reference
1-5-19 1-5-19
9803/3750-05 (1-06-00)
Fig 52. Ram Piston Nut Removal/Fitting Rig
993/99525 Rig Assembly (not including spanners and ram)
993/99522 Anchor Side Plate (supplied loose unwelded)
993/99523 Anchor Cross Member (supplied loose
unwelded)
993/99524 Ram Eye End Modification Plate Assembly
556/43400 Lift Ram
545/18000 Lynch Pin
811/50232 1.1/4in Pivot Pin
