Section 1-5 - General Information
Service Tools
Tool Detail Reference
1-5-18 1-5-18
9803/3750-05 (1-06-00)
Fig 49. Spool Clamps
992/09100 Spool Clamp
892/00011 Spool Clamp
Fig 50. 892/00180 - Seal Fitting Tool
Seal Fitting Tool for fitting 'O' ring and back-up ring to
Danfoss Orbitrol Unit.
892/00181 - Replacement Plastic Boss
Fig 51. Ram Piston Nut Removal/Fitting Spanner
993/99512 Spanner 55 mm A/F
993/99513 Spanner 60 mm A/F
993/99514 Spanner 65 mm A/F
993/99515 Spanner 70 mm A/F
993/99516 Spanner 75 mm A/F
993/99517 Spanner 85 mm A/F
993/99518 Spanner 90 mm A/F
993/99519 Spanner 100 mm A/F
993/99520 Spanner 110 mm A/F
993/99521 Spanner 115 mm A/F
SSP0046 Spanner 80 mm A/F
SSP0047 Spanner 95 mm A/F
JS07050
