jcb 86C-1 - Main Component Locations

About the Product
Description
9 9821/6200-7 9
Before you do a maintenance task, make the product safe.
Main Component Locations
Figure 3.
A
B
C
D
E
F
G
A Dipper (part of the excavator arm) B Boom (part of the excavator arm)
C Cab (contains the operator station) D Upper structure
E Undercarriage F Dozer blade
G Bucket
