jcb JCB-CS1500 User Manual

JCB, SO53 3LE
www.JCBDIY.com
Customer Helpline 0333 0143092
1.
Hand grip area
2.
On/off switch
3.
Auxiliary handle
4.
Bevel scale
5.
Parallel guide locking screw’
6.
Bevel lock button
7.
45
°
Mark
8.
0
°
Mark
9.
Bevel track
10.
Parallel guide
11.
Fixed guard
12.
Saw blade
﹡
13.
Lower blade guard
14.
Lower guard lever
15
. Base plate
16.
Dust tube
17.
Lock off button
18.
Spindle lock button
19.
Depth of cut scale
20.
Depth of cut adjustment lever
21.
Spanner (See A)
22.
Blade bolt (See A)
23.
Outer flange (See A)
24.
Inner flange (See A)
25.
Spindle (See A)
﹡ Not all the accessories illustrated or described are included in standard
delivery.
