blade (12) to be located onto the
spindle and against the inner flange
(24).
5) Refit the outer flange (23) and
whilst holding down the spindle
lock button (18) you can refit the
blade bolt (22) and hand tighten in
a clockwise direction.
6) Finally, use the spanner (21) and
spindle lock button (18) to securely
tighten the blade bolt with 1/4 turn
more than finger tight.
Warning: Saw blade teeth
are very sharp. Wear gloves
for protection.
OPERATION
1. SAFETY ON/OFF SWITCH
Your switch is locked off to prevent
accidental starting. Depress lock
off button (17) then on/off switch
(2) and release lock off button (17).
Your switch is now on. To switch off,
just release the on/off switch.
2. HAND GRIP POSITION
Always hold your saw firmly with
both hands when operating. The
right and wrong ways to support
large work pieces are shown in B
and C.
