Reduction Gear - JS160
Inspection
Part
Spindle 2
Coupling gears 8
Pins 17
† Carrier 3
† Cluster gears 6
† Shafts 9
† Thrust collars 14
† Bearings 25
† Parallel pins 34
Ring gear 4
Ring gear 5
Sun gear 7
Coupling gear 8
Coupling 19
Thrust bearing 20
Distance piece 12
Bearings 24
Replace if these conditions exist
a Excessive damage or wear.
a Excessive damage or wear.
b Uneven tooth wear on cluster gears 6.
c Rotation of cluster gears 6 not smooth.
a Uneven wear or damage to gear teeth.
a Uneven wear or damage to gear teeth.
b Worn splines.
a Uneven wear or pitting on teeth.
a Worn splines.
a Axial clearance to coupling gear 8 and cover 13 exceeds 0.8 mm (0.031 in).
a Sliding surface scratched or worn.
a Pressure marks visible.
b Flaking.
c Uneven wear.
† If any of these components show signs of the conditions listed, renew the complete carrier assembly.
Carrier
Assembly
