6 - 1
Section 1
General Information
9803/6400
Section 1
6 - 1
Issue 1
Service T
ools
(continued)
SECTION F - TRANSMISSION
T
rack Motor Jig
SST0028
Inner Rail Press Jig
SST0029
Snap Ring Jig
SST0030
Oil Seal Jig
SST0031
Case Fixing Jig
SST0032
Bearing Jig
(All dimensions are in mm.)
ø49.5
100
ø40.5
70
ø59.5
10
ø40
SST0028
SST0029
SST0030
SST0031
SST0032
ø115
ø65
185
140
ø61.5
ø45
180
ø54
ø50.5
9
11
