jcb JS260 User Manual

10 - 10
Section C Electrics
9803/6400
Section C
10 - 10
Issue 1
CAPs II Diagnostic system
SELECT MONITOR MODE CLOCK WINDOW
SWITCH WINDOW WINDOW INDICATION ITEM VALUE
0 CH; 4 H, S, L or F Time
1 1 H, S, L or F Hour Meter
2 2 H, S, L or F Machine actual working hours
3 3 1 Hours spent in S Mode
4 3 2 Hours spent in H Mode
5 3 3 Hours spent in L Mode
6 3 4 Hours spent in F Mode
7 4 H, S, L or F Travel hours
8 5 H, S, L or F Swing hours
9 6 H, S, L or F Excavating hours
10 7 H, S, L or F Hammer hours
11 8 1 Water temperature 1st bar hours
12 8 2 Water temperature 2nd bar hours
13 8 3 Water temperature 3rd bar hours
14 8 4 Water temperature 4th bar hours
15 8 5 Water temperature 5th bar hours
16 8 6 Water temperature 6th bar hours
17 8 7 Water temperature 7th bar hours
18 8 8 Water temperature 8th bar hours
19 8 9 Water max. temperature reached †
20 9 1 Oil temperature 1st bar hours
21 9 2 Oil temperature 2nd bar hours
22 9 3 Oil temperature 3rd bar hours
23 9 4 Oil temperature 4th bar hours
24 9 5 Oil temperature 5th bar hours
25 9 6 Oil temperature 6th bar hours
26 9 7 Oil temperature 7th bar hours
27 9 8 Oil temperature 8th bar hours
28 9 9 Oil max. temperature reached †
29 10 1 Engine rpm below 1000 rpm hours
30 10 2 Engine rpm 1000 - 1200 rpm hours
31 10 3 Engine rpm 1200 - 1400 rpm hours
32 10 4 Engine rpm 1400 - 1600 rpm hours
33 10 5 Engine rpm 1600 - 1800 rpm hours
34 10 6 Engine rpm 1800 - 2000 rpm hours
35 10 7 Engine rpm 2000 - 2200 rpm hours
36 10 8 Engine rpm above 2200 rpm hours
37 11 H, S, L or F Ignition switch ON/OFF No. of times operated
38 12 H, S, L or F One touch idle No. of times operated
39 13 H, S, L or F Auto idle No. of times operated
Channel 4: Performance logging sheet
† Remember this is a digital value and must be converted to a temperature using the equation on page 10-6.
